Atlas AA-GPN1200 Sound Masking Generator
The Atlas Sound AA-GPN1200 analog signal generator is ideal to use for many basic Sound Masking systems. The analog topology design eliminates repeating cycles commonly found in other manufactures digital designs. The AA-GPN1200 supports selections between Pink or White noise signals. This generator incorporates a variable balanced output and will deliver a 1V balanced output allowing it to match input circuits of Atlas Sound equalizers and amplifiers. Also a variable Hi-Cut filter when engaged, supports most equalizing requirements for most basic Sound Masking systems. The EQ filter operating range is between 1 kHz and 8 kHz with a slope of 6 dB per octave.
This small but effective generator can be used standalone or rack mounted. If multiple zones are required up to three AA-GPN1200 can be mounted onto a single 1 RU panel. The balanced output connection is via a Phoenix type (Euro block) connector. Rear mounted controls also help prevent unauthorized tampering.
Tech Data
- Compact
- Analog Topology
- Balanced Output
- Selectable Between Pink & White Noise
- Defeatable EQ
- Variable Hi-Cut Filter
- Variable Gain
- Stand Alone or Rack Mountable
- Rear Panel Adjustments
Specifications
- Filter Selection White, Pink Noise
- Gain Controls
- PRE EQ 500mV
- POST EQ 1V
- Line Output Balanced, Phoenix Type Connector
- EQ Control Variable Hi Cut 1kHz - 7kHz, Bypass Switch
- Power Supply UL Rated External 24VDC
- Panel Finish Black
- Chassis Width 4" (100mm)
- Chassis Height 1.75" (45mm)
- Chassis Depth 3.16" (80mm)
- Rack Mount Panel Width 19" (485mm)
