The ANX-70 is a compact two-way loudspeaker and was engineered to provide full range sound projection in a variety of indoor environments Its enhanced speech intelligibility ensures excellent coverage throughout the listening area.
A top quality 70 volt line transformer with minimal saturation is built into the unpowered speaker. The transformer taps are set at 30W, 10W and 5W.
The ANX-70 is magnetically shielded for use near video monitors, and the speaker case is designed with an adjustable mounting bracket allowing for easy wall and ceiling installation.
Sleek and discreet in a clear or translucent grey high impact polystyrene.
- Technical Specifications
- Frequency Range: 80 Hz - 20 kHz (-10 dB)
- Nominal Coverage: 105ø x 105ø
- Nominal Sensitivity: 86 dB SPL, 1W @ 1 m (3.3ft)
- Maximum SPL @ 1m 108 dB continuous peak pink noise, 103 dB continuous average
pink noise, 100 dB continuous average music or speech
- Crossover Type First Order High-pass
- Input Selection 70 volt-line transformer taps @ 5W, 10W, and 30W
- 1/4" (6.0 mm) 8 Ohm
- Transducers
- Low-Frequency 4" (100 mm) woven carbon fiber w/ treated cloth edge surround,
- 1" (25 mm) voice coil on aluminum former, magnetically shielded
- High-Frequency 5/8" (10 mm) dome of PEI
- Enclosure Material ABS
Grille Painted perforated steel
- Mounting Use with SB-1BK Speaker stand bracket, SB-3BK wall mount bracket, SB-360BK swivel wall mount bracket, RM-1BK single rack mount kit,
- RM-12BK dual rack mount kit. Not included
- Dimensions: (HWD) 5.25 x 8.375 x 9" (13.3 x 21.3 x 22.9 cm)
- Net Weight (ea) 4.2 pounds (1.9 kg)
- (Features & Specifications Subject To Change Without Notice)
