Blackmagic BDLKHDEXT3 Decklink HD Extreme 3 SD/HD/2K 4:4:4 Video Card with SDI
Blackmagic BDLKHDEXT3 Decklink HD Extreme 3 SD/HD/2K 4:4:4 Video Card with SDI
The ideal solution for connecting to any camera, deck or monitor, all with the same card. DeckLink HD Extreme is the first DeckLink card to feature both SDI and analog I/O, and HDMI connections that instantly switch between high definition and standard definition video. New DeckLink HD Extreme features 3 Gb/s SDI technology so you can connect RGB 4:4:4 and 2K via a single SDI connection, and an extra SDI out for Dual Link 4:4:4. Use with the latest PCI Express Mac and Windows computers for the world's highest quality editing, effects and broadcast paint solution.
DeckLink HD Extreme is the only solution that connects to SDI, HDMI, component analog, NTSC/PAL and S-Video equipment for capture and playback, while instantly switching between SD, HD and 2K. DeckLink HD Extreme includes 2 channels of AES/EBU audio in and out with a sample rate converter on the AES/EBU input as well as 2 channels of XLR professional analog audio in and out. Work with the widest range of equipment, such as HDCAM, HD-D5, HDCAM SR, Betacam SP, Digital Betacam, HD receivers, HDV cameras, televisions, mixers and more. DeckLink HD Extreme now supports Dual Link SDI and 3 Gb/s SDI, so you can capture and play back 4:4:4 video when used with decks such as Sony HDCAM SR™, or view real time playback of 2K film resolution at 24 fps with Blackmagic Design's HDLink Pro.
DeckLink HD Extreme's super fast 10 Gb/s connection plugs directly into your editing software's real time effects processing. Unlike FireWire products, you get all CPU time for real time effects, as only PCI Express lets you upgrade to HD without limiting real time effects. The higher speed of PCI Express also easily handles advanced formats such as full resolution 2K digital film. Only high speed PCI Express ensures that when you upgrade your studio to high definition, you'll get full real time effects.
The new DeckLink HD Extreme is the first capture card to include high speed 3 Gb/s SDI connections. 3 Gb/s SDI is the latest version of the SDI video standard that allows 4:4:4 RGB and 2K film connection with a single BNC type connection. 3 Gb/s SDI runs twice the data rate of normal HD-SDI video, however it can instantly switch to traditional standard definition and high definition SDI. 3 Gb/s SDI allows 4:4:4 RGB workflow or full resolution 2K feature film quality 24 fps 2048 x 1556 capture and playback. 2K via SDI allows a revolutionary change to feature film workflow as now you can connect film resolution video around your facility using the same familiar workflow as a "normal" video job! Only DeckLink HD Extreme gives you film editing features built in for no extra cost!
You'll love the full resolution HDMI input and output built into DeckLink HD Extreme. Use the HDMI output for connecting to any HDMI television or video projector for full HD resolution monitoring at much lower cost than a dedicated HD broadcast monitor. Imagine presenting your work to your clients using cinema size large screen video projectors or televisions! Use the built in HDMI input for capturing from cameras with HDMI outputs. Unlike FireWire capture, using the HDMI output of consumer cameras means you get the highest quality uncompressed video from the camera, or you can use the native compression of your editing software, such as uncompressed, JPEG, DVCPRO HD, and ProRes. Unlike FireWire compression, using the native compression of your editing software, combined with high speed 10 Gb/s PCI Express gives you all CPU time for maximum real time effects playback direct to large screen displays and broadcast monitors.
Fully compatible with SD-SDI and HD-SDI 4:2:2, new DeckLink HD Extreme also features Dual Link HD-SDI 4:4:4 connections for feature film quality. Dual Link 4:4:4 is used on the latest Sony HDCAM SR decks, and contains additional color detail giving you full RGB color bandwidth and extra precision of up to 10 bit SDI video. When connected via PCI Express to a host computer, this higher quality video can be captured and played back completely uncompressed for amazing feature film quality. DeckLink HD Extreme also takes a new lead in quality with the latest 3 Gb/s SDI technology, so you can connect RGB 4:4:4 and 2K via a single SDI connection. 3 Gb/s SDI technology is the video standard of the future for post production, and allows "beyond HDTV resolutions". DeckLink HD Extreme is ideal for connecting to Digital Betacam™, Panasonic HD-D5™ or the new Sony HDCAM SR decks. Uncompressed 10 bit video is the highest quality possible from the SDI television system, and only uncompressed video will hold up under heavy working conditions demanded by clients today while retaining a delicate film look.
Photoshop™ plug-ins are included for capture and output of still frames. Blackmagic FrameLink™ lets you instantly access QuickTime and AVI media as DPX files. Blackmagic Deck Control™ lets you control a deck remotely via RS-422 for capture and playback of clips with timecode accuracy and Blackmagic Disk Speed Test™ checks your disk array in frames per second.
