High Resolution CCD Camera with Lens and Mounting Bracket

Created to fill the much needed gap from poor quality CCTV cameras to expensive industrial fixed lens products, this product is the answer for closed circuit applications. Where you need good quality color cameras that are rugged, easy to deploy and cost effective, the DELVCAM Extended Definition Sony based CCD color cameras fits the bill.

Designed for use in the varied fixed lens, excellent depth of field and exceptional quality color video, the DELV-XCAM-ED5 delivers. It is provided as a complete system with mounts, cables, adapters and power supplies. It is ready to use out of the box!

The ED5 uses a 1/3 SONY HQ1 CCD imaging element to provide a 512H x 492V effective pixel image. Minimum illumination is 1.0 Lux(Day) and 0.1Lux(Night) @ F1.2. S/N is greater than 50dB. Fitted with a 1/3 Auto Iris Vari-Focal 3.5mm-8mm C mounted DC driven lens, the ED5 is packed with performance. It operates on 12VDC or 24VAC @250mA. It is shipped with a 110/220 AC 12VDC adapter. The video output is via a BNC connector.
