Apantac LE-4SD Tahoma Multiviewer w/4 Analog Composite Inputs
Accepts 4 Auto-detect (SD-SDI/PAL/NTSC) video inputs. 16 channels of embedded audio per video. 16 GPI for tally/presets RS232 for 3rd party interface. 30 internal presets. Supports AXP API. With Built-in CATx extenders. Output up to 1600x1200 / 1920x1080 / 1920x1200 / 2048x1080 @ 50/60Hz.
Key Features:
- 3G ready - upgrade to 3G at any time
- Single frame processing delay
- 4 auto-detect SD-SDI, PAL/NTSC inputs
- 16 channels of embedded audio per SDI input
- 4 channels of discrete audio per input (optional)
- Supports DVI, HDMI, VGA outputs
- Supports full 10-bit HDMI 1.3 outputs
- Output resolution up to 2048x1080 (incl. 1920x1080p)
- Built-in CATx extenders - extend 1080p (DVI/HDMI)
up to 115 feet
- Built-in CATx extenders - extend 1080p (VGA)
up to 300 feet
- Multiple labels per video windows - UMD, OMD, IMD,
standalone labels
- Automatic input aspect ratio detection
- Built-in video, audio alarm detections - no audio,
audio high/low, no video, video black, video frozen
- Apantac skin technology allows on-screen graphical
elements to be designed with any graphics tool
- Field upgradable to allow discrete audio (AES/AA)
- Front panel headphone jack with volume adjustment
for audio monitoring
- Front panel buttons for quick preset recalls
- Optional redundant power supply
- 3 year limited warranty
