Doremi HDVI-20S & HDVI-20D Converters
HD-SDI, SDI, DVI & RGBHV to DVI Converter
The HDVI-20 bridges the gap between high-resolution digital video and RGB sources and the new generation of display devices with the DVI interface.
The HDVI-20 converts SDI video and DVI-D (digital or analog RGB) to DVI. It supports all popular SDI video formats including NTSC, PAL, 720p, 1080p and 1080i. In addition, the HDVI-20 provides on-screen menus and an infrared remote to switch between its 4 input formats.
Flash E-Prom memory provides for hassle free updates. Owners can download new firmware from Doremi's website to keep their HDVI-20 current.
Advanced Image Processing
The HDVI-20's advanced image processing
leaves the competition in pixel dust
Spatial Interpolation
Clear and sharp rendition of static images
Advanced De-Interlace Processing
Clear, accurate output of moving images
Temporal Processing
Smoother frame rate conversion
60Hz, 50Hz and 48Hz Output
Matches input frame rate and minimizes artifacts
Auto-Sized Output
Matches the connected display size without affecting the aspect ratio
True 1080i Output
True 1080i video output with any input
Features
SDI / HD-SDI Video Interface for Displays and Projectors
Display SDI and high definition HD-SDI video
on monitors and projectors with DVI inputs
DVI to DVI Resolution and Frame Rate Converter
The HDVI acts as a bridge between
incompatible DVI equipment
Analog RGB to DVI Converter
Convert analog RGB sources to DVI and match the
output frame rate and resolution to the connected display
4:4:4 12 bit Input via dual-link HD
HDVI-20d adds dual-link HD-SDI input for
applications that require high color precision
Color Space Conversion
HD-SDI input supports RGB, YCbCr and XYZ color space
Extra Value Remote Control
HDVI Remote Software and Remote Control
Control Software
The control software for the HDVI converter provides all the functions accessible via the
IR remote. The software also features a downloadable look up table (LUT).
Infrared Remote
Full function infrared remote controls the
HDVI's on-screen display (OSD).
Downloadable Look Up Table (LUT)
Available from the HDVI control software. Preset LUT are also included.
Input Switcher
Use the IR remote or the control software to switch between the SDI/HD-SDI or the DVI-I input.
SPECIFICATIONS
INPUT
SDI - SMPTE 259M-C (270Mb/s)
HD-SDI - SMPTE 292M (1.485, 1.485/1.001 Gb/s)
DVI-D (via DVI-I connector)
Analog RGB-HV (via DVI-I connector)
Requires a RGB to DVI-I breakout cable. Not included
Dual-Link HD-SDI 4:4:4 SMPTE 372M (HDVI-20d only)
NTSC, PAL
720p 60, 59.94, & 50Hz
1080i / 1080p 30, 29.97, 25, 24 & 23.98Hz
2048x1080p & sf 24 & 23.98Hz
DVI and Analog RGB-HV:
Interlaced and Progressive Sources up to1920x1200
Pixel clock must not exceed 165 MHz
OUTPUT
DVI-D (Digital RGB) - Female, compliant to DVI 1.0
Resolutions up to 1920x1200 (48, 50 and 60Hz)
Loop out for the HD-SDI / SDI inputs (HDVI-20s only)
Auto detects connected monitor resolution
Auto Mode: Outputs at 48, 50, or 60Hz
Frame Sync Mode: Outputs at the input frame rate
SUPPORTED DISPLAY RESOLUTIONS
The HDVI-20 supports most DVI resolutions. Below are a few:
1024x768 / 1280x720 / 1280x768 / 1280x1024
1400x1050 / 1600x1200 / 1920x1080 / 1920x1200
INTERFACE
On-Screen Display (OSD) with infrared remote control
OTHER
RS-422 for remote control and firmware upgrades
GENERAL
5 volts (screw-on connector)
External Locking Power Adapter: 100-240VAC 50-60Hz
5.4" x 3.7" x 1" (138mm x 93mm x 24mm)
