Rack Mount Power Supply System/Wall Pack Eliminator for Standard 12 VDC & AJA 5 Volt Modules
Connectronics, a leader in high quality power supply solutions for the audio visual industry presents the best solution for replacing "wall wart" style 12 and 5 Volt DC power packs.
The A/V industry uses a host of various styled 12 and 5 Volt switch mode power packs to power a variety of module products. However when you are using a quantity of these supplies in a system build, it becomes cumbersome and wastes a great deal of space.
The CTX-UNPRM address the problem by providing a 1RU rackmount power supply that has an input of 110-220V AC auto switching section. A state of the art switch mode power supply provides 4 rear panel 2.1mm power connectors with 12VDC outputs and another on the front panel that can be used for charging compatible products.
It also provides four 5pin XLR connectors that are wired for AJA 5 Volt DC modules. For 4pin XLR compatible 12VDC needs, a front panel connector provides this option. The CTX-UNPRM delivers a total of 2 Amps for 12 Volt section and 4 Amps for the 5VDC section.
System Includes:
- 1) CTX-UNPRM Universal Rackmount Power Supply
- 4) CTX-UN21M21M 2.1mm to 2.1mm 6 foot Power Cables
- 4) CTX-UNP5PS5V 5-Pin XLR Male to AJA Style 6 foot Power Cables
