Middle Atlantic UxV Series Vented Utility Shelf

Middle Atlantic UxV Series Vented Utility Shelf

Featuring fully ventilated bottom and sides for heat dissipation, these fully welded, easy-to-install shelves fit all components up to 17 3/8" wide to quickly meet all of your rackmounting needs. Made from 16-gauge steel, each unit is individually boxed. Includes 3 rear brackets to prevent components from sliding backwards. This shelf helps to save valuable space by accepting the mounting of the PD-815SC-PBSH 8 outlet, 15 amp power strip on the rear of shelf. Also allows the attachment of optional clamping bars to secure components.

The Breathe Easy™ vent pattern in the sides and bottom pan allow a generous amount of air to flow around your sensitive equipment.

Three included L brackets keep equipment in place and prevent slippage over time.

Available in 2, 3 and 4 spaces

U2V 2 rack spaces

U3V 3 rack spaces

U4V 4 rack spaces

All sizes have a usable width of 17.44 inches.

U2V 15 inches deep

U3V 15 inches deep

U4V 15.5 inches deep

The UxV shelves have the same weight capacity as their comparable solid "U" series shelf.

U2V 50 pounds

U3V 70 pounds

U4V 85 pounds
