Clover CDR4770 IP Addressable 4 Channel DVR w/MPEG-4 Compression

Features:

• Triplex (Live/Recording/Playback simultaneously)
• MPEG-4 Compression
• High Resolution 720 x 480
• Real Time Display 120 Frames/sec
• Full Real Time Recording: 120 frames/sec capacity (30 frames/sec x 4 channels)
• Programmable Recording Speed on Each Channel
• Up to 2 bays HDD: 320 GB SATA HDD Included
• 4 Video Inputs (BNC) & 4 Looping Output (BNC)
• Backup: USB port, Through Network, VCR
• Remote Controlling & Monitoring via TCP/IP (GUI & Internet Explorer)
• Event Recording by Alarm Sensor or Video Motion Detection
• Alarm Notification via E-mail by Alarm, Video Loss,Power Loss, HDD Failure
• DDNS support
• 1 CH Audio In & Out
• Pan/Tilt Control
• Remote Controller

Package Includes:

• 1 - 4Ch Standalone DVR
• 1 - AC Power Supply
• 1 - Software for Remote Setup
• 1 - Instruction Manual
• 1 - Warranty Registration Card
• 1 - Remote Controller

Specification:

• Operating System: Embedded Linux
• TV System: NTSC 60fields/sec, AL 50fields/sec
• Resolution: NTSC 720 x 480/720 x 240/360 x 240, PAL 720 x 576/720 x 288/ 360 x 288
• Video Inputs: 4 BNC 1.0Vp-p Composite 75 ohms
• Video Outputs: 1.0Vp-p Composite 75 ohms, 3 outputs: 1-VGA output, 1-Composite, 1-Spot
• Audio In/Outputs: 1 Ch
• Real Time Display: 120 Frames/sec
• Recording Frame Rate: 120 Frames/sec, Programmable on
• each Channel
• Algorithm: MPEG-4 (Average file size: 4KB)
• Recording: Schedule, Continuous, Event Recording by Motion
• Hard Disk Drive: Up to 2 bays, 320GB SATA HDD Included
• Replay: Forward, Reverse (fast, normal)
• Backup: USB port, Ethernet & VCR
• Alarm In: 4 inputs
• Alarm Output: 1 relay output
• Network: Ethernet 10/100M
• Power Source: DC 12V 5A
• Operating Temp.: 40F to 122F
• Humidity: 10 to 90%
• Dimensions: 430(W) x 320(D) x 45(H) mm
• Weight: 12 ibs
