4ch Multi Viewer
MV-40F
Featuring 5 Split Screen and Three Types of Picture-in-Picture Screens.
- Display camera inputs full screen, 2-split, 3-split, 4-split, or P-in-P.
- Auto sequential switch function between four channels.
- VTR input / output jacks.
- Freeze camera input views as necessary, 2 x zoom views on playback.
- Auto sequence between inputs and alarm/lost video detection functions.
- Built-in video timer.
- Input up to 8 characters per camera channel, title positionable.
Applications
- Surveillance in a store.
- Surveillance in commercial institutions, such as a bank, a hotel, an amusement center, and a theater.
- Surveillance in industrial institutions, such as a manufacture line, etc.
Specifications
- Standard - NTSC or PAL (Factory setup)
- Video Inputs - Analog composite: 1.0Vp-p, 75O or loopthrough (automatic terminal), 4ea., BNC (color or B/W) (asynchronous acceptable)
- VTR Inputs - Analog composite: 1.0Vp-p, 75O, 1ea., BNC
- Monitor Output - Analog composite: 1.0Vp-p ñ0.1V, 75O, 1ea., BNC (Full screen view or split screen view)
- VTR Output - Analog composite: 1.0Vp-p ñ0.1V, 75O, 1ea., BNC
- Display Modes - Full, Quad, P-in-P 1-3 (1 full screen and between 1-3 inset screens), 2-split and 3-split vertical, 2-split and 3-split horizontal (VTR playback allows Quad screens to be Individually zoomed, P-in-P screens can be user positioned and half size screen view of 2-split or 3-split can be user adjusted.)
- Camera Title - Alphabet, numbers, symbols, 8 characters / 1 line max, positionable.
- Data / Time - MM-DD-YYYY, H:M:S (24 hour indication) for NTSC,
DD-MM-YYYY, H:M:S for PAL as factory default.
Data format YYYY-MM- DD can also be selected.
- Alarm display - Automatically changes to alarm screen, "ALARM" text display
- Screen freeze - Each channel can be frozen
- Interfaces - Remote/alarm input/output connector, 25-pin D-sub (female)
Remote: TTL negative logic pulse (more than 100ms width)
Time Adjust: TTL negative logic pulse (more than 100ms width), minute signal
Alarm Input: TTL negative logic pulse (more than 100ms width) or level
Alarm Output: Make break contact, max. 24VDC 100mA
RS-232C: Asynchronous, full duplex, 9600 bps transmission speed, 8-bit data length, 1-bit stop bit, and no parity
- Storage System - Menu setting details and time for timer are backed up, maintained for approximately 5 years after the power is shut down for Setting Data (when using a lithium battery)
- Temperature / Humidity - 0§C - 40§C / 30% - 90% (no condensation)
- Power - 100V - 240V AC ñ10%, 50/60Hz
- Consumption - Approx. 16VA (10W) at 100VAC
Approx. 22VA (12W) at 220VAC
- Dimensions / Weight - 212 (W) x 44 (H) x 350 (D) mm / Approx. 1.9 kg
- Accessories Operation manual / AC cord
|
