Doremi Labs GHX-10 Cross Converter
The GHX-10 features HDMI, DVI, and SDI connectors that allow for any
input to be converted to any output format or scan rate. It supports both
SD and HD video and employs high quality 12 bit bicubic interpolation to
ensure the highest quality picture.
Doremi has listened to the demands of video professionals and included
many advanced features such as audio support, sync output and genlock.
The GHX-10 also features the latest video technology in the form of
dual-link SDI and 3Gb/s SDI connectors for 4:4:4 2K film resolution.
Thanks to its comprehensive video format support the GHX-10 can tackle
many conversion tasks. The GHX-10 can be used as a computer DVI to
HD-SDI converter, a HDMI resolution converter, or as a HD video upconverter
or downconverter and much more.
The GHX-10 supports up to 8 channels of AES, HDMI and SDI audio. The
audio can be embedded or de-embedded to the separate AES BNC
connectors or delayed to match the video.
A two line LCD display and scroll wheel simplify navigation through the
GHX-10's menus. A USB connection for remote operation and an infrared
remote control are also provided. Firmware can be upgraded via a micro
SD card or via USB.
- Universal Inputs
DVI, HDMI, SDI, HD-SDI
Dual Link HD-SDI
- Universal Outputs
DVI, HDMI, SDI, HD-SDI
Dual Link HD-SDI
- New HD-SDI at 3Gb/s
Supports 4:4:4 at 2K
Resolution on one BNC
- HD 1920 to 2K 2048
Upconversion
- Genlock Input
For output synchronization
- Audio Support
8 channels SDI, AES, HDMI
with adjustable delay for video
- LCD Display,
Navigation Wheel,
USB, and Infrared
Remote
- Software Upgrade
Via SD Card or USB
