Hall Research SC-1080D Multiformat HD Scaler with both High Definition and Analog Inputs

Combines all of the functions of several products in one featuring both high definition analog as well as digital inputs. Two simultaneous outputs are available, one analog (RGBHV, or Y Pb Pr), and one digital DVI-D (HDMI compatible).

The SC-1080D outputs resolutions anywhere from 480i to 1080p (HDTV) or VGA to WUXGA (PC). Users may select inputs via the front panel, the included IR-remote, or by issuing ASCII RS-232 commands.

Features

• High definition digital (DVI / HDMI) and analog (PC VGA / YPbPr) Scaler that accepts PC RGB (up to UXGA), HD Component (480i up to 1080p) and DVI (up to WUXGA) and scales them to DVI and analog outputs at user specified resolutions
• HDCP (HDMI) compliant DVI input and output
• Output resolution selectable from 480i to 1080p (HDTV) and VGA to WUXGA (PC).
• RS-232 Control port, IR remote, and Front Panel Controls
• Native output mode ensures optimal resolution on the screen based on the display's EDID
• Output picture adjustments for brightness, contrast, RGB levels
• State of the art scaling engine for sharp and flicker free output
• Built-in Universal Power Supply with standard IEC-320 jack
