    Bittree B422-NI6S/6 2 x 6 1 RU RS422 Patchbay BLACK

    Manufacturer: Bittree

    Item #: B422-NI6S/6   •   MFG #: B422-NI6S/6




    Our RS-422 Programmable Data Patchbay allows you to switch circuits between full-normal and non-normal and back again - quickly, easily and reliably. This flexibility allows the patchbay to serve as the foundation for virtually any new, reconfigured or legacy installation. It's built to strict electrical and mechanical specifications to guarantee exceptional performance in traditional serial data applications, and is ideal for edit bays and machine rooms in post-production, broadcast and duplication. It can also accommodate remote-delegation protocols such as Sony and Lynx.

    • Features

      • Robust six-wire circuits accommodate RS422 signals - and provide two extra circuits for additional applications and protocols
      • Handles bi-directional signals such as SMPTE 207M RS-422, RS-232 and other general purpose interface applications
      • Programming shunts allow users to easily change between full-normal and non-normal circuits
      • Programming shunts located underneath the patchbay dust cover. Full-normals have shunts inserted, non-normals have shunts removed
      • Jacks rated to 30,000 minimum insertion cycles
      • Copper-nickel-silver alloy leaf springs with gold-plated cross bar switching contacts and nickel-plated sleeve bushings
      • Precision-stamped reinforced steel jack frame
      • Panels made from 3/16" solid aluminum with a durable powder-coat finish
      • Large, user-friendly designation strips
    • Specifications

      • Data RS422; 2x6; 1RU; Black Panel; Non-Normal Grounds.
