Galaxy Audio AXS-18RM - 18 Channel Analog Audio Rack Mixer
  • Galaxy Audio AXS-18RM - 18 Channel Analog Audio Rack Mixer
  • Galaxy Audio AXS-18RM - 18 Channel Analog Audio Rack Mixer

Questions? Ask a Markertek Expert:
800-522-2025 Email

Galaxy Audio AXS-18RM - 18 Channel Analog Audio Rack Mixer

Manufacturer: Galaxy Audio

Item #: GXY-AXS-18RM   •   MFG #: AXS-18RM



List Price:$699.99
Our Price:$449.99

free ship


Availability: Usually ships in 3-10 business days
i
This item is currently out of stock and will ship the minute we receive it – normally 3-10 business days. Need it sooner? Call 800-522-2025 and we'll make it happen,or email Customer Service for expedited delivery options. Certain Non-Stock Items Valued over $50.00 may Ship FREE UPS GROUND in the Continental US. Multiple quantities of the same non-Stock Item Valued below $50.00 may be ordered to meet the $50 minimum order requirement to qualify for Free UPS Ground Freight. This offer does not apply to certain freight-intensive or hazardous items. Certain restrictions may apply.




    Share!





    The new AXS line features a full line of analog audio mixers. The AXS series offers 5 different desk top models with 3 available in a rack mount version. All models have a USB connection to link to a computer for stereo playback or recording and have +48V phantom power to the XLR inputs. Additionally, most XLR inputs provide an easy to use single knob compression. Most models feature a 3 band EQ with sweep-able mid-range, and low cut filter. All models include AUX sends on each channel which are either pre/post or switchable for monitoring/FX or external send.

    All AXS models have built in Studio grade DSP FX with 16 effects. Effects include Reverb, Chorus, Flanger, Delay, Pitch Shifter, and Multi-Effects. Each effect has a storable user parameter and a tap button with a tempo light that provides for delay and echo settings.

    Each channel also provides the user with Clip LEDs, Mute, Subgroup Routing, Solo, L/R Panning and PFL. The mono channels also feature 1/4" TRS inserts for flexible connection to outboard effects and processing. Whether using in a fixed install or on the road, the 60mm logarithmic faders and sealed rotary controls will provide clean, reliable sound.


    • Features

      • 18 Input, 10XLR Mic Input & 4 Stereo Inputs
      • 10 +48V Phantom Powered Mic Preamps
      • 8 Easy to use Built in Compressors
      • 3 Band EQ with Sweep Mids on Each Channel
      • 16 Effects with Tap
      • USB Audio Interface
      • 8 Channel Inserts
      • 4 AUX Sends Per Channel
      • PFL on Each Channel
      • Balanced Main Outputs
      • Headphone Output
      • 60 mm Logarithmic Faders
      • Switching Power Supply

    • Specifications

      • Max. Input Level: Mic +22dBu, Other Line +20dBu
      • Max. Output Level: Main XLR +28dBu, Other Output +22dBu
      • Meters: 3 Color LED
      • Sensitivity: 0VU=+4dBu
      • Master Meter: 12 Segment, -30dB to clip
      • Channel meter: Red LED, clip
      • Frequency Response: +/- 1dB, 20Hz - 30KHz
      • Mic CMRR at 1kHz:>70dB typical
      • THD+n at +14dBu at 1kHz: Mic to mix out <0.005%
      • Crosstalk (@1KHz): Fader shutoff >89dB, Mute shutoff >89dB
      • Noise, rms 20Hz to 20kHz: Mic Input E.I.N -129dBu
      • Main mix fader unity,
      • Channel fader down <-95dBu(-97dB S/N)
      • Main mix fader unity,
      • Channel fader unity <-82dBu(-86dB S/N)
      • Channel HPF: 18dB/oct below 75Hz
      • Mono EQ:
      • Lo: +/-15dB shelving at 80Hz
      • Mid: +/-15dB peak at 100Hz to 8kHz
      • Hi: +/-15dB shelving 12kHz
      • Stereo EQ:
      • Lo: +/-15dB shelving at 80Hz
      • Mid-Lo: +/-15dB peak at 500Hz
      • Hi-Mid: +/-15dB peak at 3kHz
      • Hi: +/-15dB shelving at 12kHz
      • DSP: Converter 24-bit sigma-delt, 64/128-times oversampling, Sampling Rate 40kHz
      • USB: Audio Stereo In/Out, Connector Type B, Converter 16-bit, Sampling Rate 48kHz
      • Power Supply: 110-240VAC,50/60kHz
      • Power Consumption: 50 watts
      • Fuse: 100-240VAC,T 1.6A, 250V, 5x20mm
      • Dimensions: 5.12" x 19" x 19.1" (130 x 483 x 485 mm)
      • Weight: 18 lb (8.14 kgs)

    • Warranty

      • 3 Years
