ICM DB15BNCHD RGB 22-24 AWG Double Bubble Style for BNC High Definition (PURPLE)

ITEM #: ICM-DB15BNCHD MFG #: DB15BNCHD

Primary Image

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the ICM-DB15BNCHD

DB15BNCHD - Overview

The DB15BNCHD is ICM's one-piece High Definition BNC Broadcast compression connector that fits most brands of 23-24AWG RGB/ mini coaxial cable.

  • Specifications:

    • 75 Ohm Construction
    • DC-1 GHz > -35 dB Return Loss < 1.04 VSWR
    • DC-2 GHz > -29 dB Return Loss < 1.07 VSWR
    • DC-3 GHz > -32 dB Return Loss < 1.07 VSWR
    • Connector holding strength exceeds cable tensile strength
    • Body Material Brass
    • Body Material (Plating) Nickel

  • GTIN:

    0845671005233
