Kramer VM-24HDCP 2:4 DVI Distribution Amplifier

ITEM #: KR-VM-24HDCP MFG #: VM-24HDCP

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the KR-VM-24HDCP

VM-24HDCP - Overview

The VM-24HDCP is a high-performance distribution amplifier for DVI signals. The unit reclocks and equalizes one of two input signals and distributes it to four identical outputs.

  • Specifications:

    • INPUTS: 2 DVI, 1.2Vpp on a DVI Molex 24-pin (F) connector; DDC signal 5Vpp (TTL).
    • OUTPUTS: 4 DVI, 1.2Vpp on DVI Molex 24-pin (F) connectors; DDC signal 5Vpp (TTL).
    • MAX. DATA RATE: 6.75Gbps (2.25Gbps per graphic channel).
    • CONTROLS: EDID SELECT, EDID READ, IN 1, IN 2 buttons, RS-232, IR.
    • INDICATOR LEDs: OUTPUT STATUS LEDs.
    • POWER CONSUMPTION: 100-240V AC, 50/60Hz 17VA.
    • DIMENSIONS: 19" x 7" x 1U W, D, H, rack mountable.
    • WEIGHT: 2.5kg (5.5lbs) approx.
    • ACCESSORIES: Power cord, rack "ears", null-modem adapter, Windows-based control software, infrared remote control transmitter


  • GTIN:

    7291063002992
