Kramer VP-460 3-Input Analog & 3G HD-SDI ProScale Presentation Switcher/Scaler
  • Kramer VP-460 3-Input Analog & 3G HD-SDI ProScale Presentation Switcher/Scaler
  • Kramer VP-460 3-Input Analog & 3G HD-SDI ProScale Presentation Switcher/Scaler
Questions? Ask a Markertek Expert:
800-522-2025 Email

Kramer VP-460 3-Input Analog & 3G HD-SDI ProScale Presentation Switcher/Scaler

Manufacturer: Kramer

Item #: KR-VP-460   •   MFG #: VP-460


List Price:$1,495.00
Our Price:$1,196.00

free ship
Availability: In Stock
Item is Available for immediate shipping from our warehouse.



    The VP-460 is a high-quality presentation switcher and scaler with PIP for computer graphics, composite video and 3G HD-SDI signals. It scales the video, embeds the audio and outputs the signal to the HDMI output, as well as to the SDI output together with a digital audio output.

    • Features

      • K-IIT XL Picture-in-Picture Image Insertion Technology - Ultra-stable picture-in-picture, picture-and-picture, and split screen capability. Any video source can be inserted into or positioned next to an SDI video source or vice versa with window positioning and sizing controls.
      • K-Storm Scaling Technology - Kramer's extremely high performance scaling technology for converting the incoming video signal with a minimum of motion artifacts. Up- and down-scaling of computer graphics video signals is possible.
      • Ultra-Fast Fade-Thru-Black (FTB) Switching - Video switching transitions are clean and ultra-fast. The video fades to black and the new input fades from black for smooth, glitch-free switching. The output signal provides constant sync so the display never glitches.
      • HDTV Compatible.
      • Multi-Standard Operation - SDI (SMPTE 259M), HD-SDI (SMPTE 292M) and 3G HD-SDI (SMPTE 424M).
      • Video Inputs - 1 computer graphics on a 15-pin HD connector, 1 composite video on an RCA connector, 1 SD/HD/3G HD-SDI with loop on BNC connectors.
      • Scaled Outputs - 1 HDMI, 1 SD/HD/3G HD-SDI on a BNC connector.
      • 40 Output Resolutions - Up to WUXGA, 1080p and 2K.
      • HDMI Deep Color Support - For inputs and outputs.
      • Luma Keying - Via PIP window.
      • Vertical Keystoning.
      • Built-in ProcAmp - Color, sharpness, contrast, brightness and gamma are set individually for each input.
      • 3D Comb Filtering - Provides the best quality color separation for composite video inputs.
      • Built-in Time Base Corrector - Stabilizes unstable video sources.
      • Powerful Noise Reduction Filters - Temporal, block, mosquito and combing.
      • Picture Zooming - From 100% to 1600% on both main and PIP picture.
      • De-interlacing - 3:2 and 2:2 pull-down; 24sf handling.
      • Multiple Aspect Ratio Selections - Follow input, follow output, best fit, letterbox and overscan.
      • Dual Window Display - Preset picture-in-picture, picture-and-picture and split screens, as well as customized window layouts.
      • Audio Inputs - 1 computer graphics on a 3.5mm mini-jack connector, 1 CV on RCA connectors; embedded audio (user selectable) on the SDI input.
      • Audio Outputs - 1 S/PDIF on an RCA connector, embedded audio on the HDMI and SDI outputs.
      • Power Save Modes - Options for efficient energy use.
      • Advanced EDID Management - For each input and each output.
      • Non-Volatile Memory - Saves final settings.
      • Firmware Upgrades - Via RS-232.
      • Flexible Control Options - Front panel buttons, OSD (on-screen display) via front panel buttons or IR remote (remote control included), Control Application software for use via RS-232.
      • Desktop Size - Compact size. 2 units can be rack mounted side-by-side in a 1U rack space with an optional RK-1 adapter.
    • Specifications

      • INPUTS: 1 computer graphics on a 15-pin HD connector, 1 composite video, 1Vpp @75? on an RCA connector, 1 SD/HD/3G HD-SDI on a BNC connector, 1 unbalanced stereo audio on a 3.5mm mini jack connector, 1 unbalanced stereo audio on 2 RCA connectors.
      • OUTPUTS: 1 SD/HD/3G HD-SDI on a BNC connector, 1 HDMI (deep color) connector, 1 S/PDIF digital audio on an RCA connector.
      • OUTPUT RESOLUTIONS: [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected],[email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], [email protected], 480i60, 480p60, 576i50, 576p50, 720p50, 720p59.94, 720p60, 1080p23.976, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 2K50, 2K60.
      • CONTROLS: Front panel buttons, OSD, IR remote control, RS-232 on a 9-pin D-sub connector.
      • OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F).
      • STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F).
      • HUMIDITY: 10% to 90%, RHL non-condensing.
      • POWER CONSUMPTION: 5V DC, 2.90A.
      • DIMENSIONS: 21.5cm x 16.3cm x 4.4cm (8.5" x 6.4" x 1.7") W, D, H.
      • WEIGHT: 0.9kg (1.98lbs) approx.
      • ACCESSORIES: Power supply, IR remote control.
      • OPTIONS: RK-1 rack adapter.
