Lectrosonics SPN1612 Digital Matrix Audio Processor - 16 In / 12 Out - Aspen Net

ITEM #: LEC-SPN1612 MFG #: SPN1612

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the LEC-SPN1612

SPN1612 - Overview

From small installations all the way up to sophisticated, multi-layered systems, these ASPEN mixers are the perfect compliment to your audio integration. Unlimited input expansion and 48 mix buses give you phenomenal scalibility. The Proportional Gain Algorithm provides seamless auto-mixing and integrates easily with with echo cancellation, analog mixing consoles, or any other type of audio system. And with TCP/IP addressibility for control through Ethernet, ASPEN is now part of your network.

Any way you look at it, the ASPEN line from Lectrosonics is your new choice in professional DSP audio processing systems.

  • Features:

    • Ultra low noise input preamps
    • Full crosspoint matrix with 48 outputs
    • Unlimited input expansion
    • TCP/IP Ethernet addressable
    • Seamless auto-mixing with PGA at the matrix crosspoints
    • Simultaneous multi-point 3rd party and native control
    • Ultra-low latency
    • Automatic Master/Slave detection
    • Single CAT6 interconnection carries data, audio and control signals


  • Specifications:

    • Matrix: 48 mix buses with full output matrixing
    • ASPEN port: 1Gbs control and audio data between ASPEN units
    • Inputs:
    • SPN812: 8 mic/line
    • SPN1612, 1624: 16 mic/line
    • SPN2412: 24 mic/line
    • Gain: 0 dB to 56 dB, programmable in 8 dB steps
    • Input Level: 0 dBu nominal, max 20dBu
    • Input impedance: 8 k Ohms differential mode, 2 k Ohms common mode
    • Phantom power: True 48 Volt
    • Outputs:
    • SPN812, 1612:
    • 1-8 line level (0 dBu),
    • 9-12 mic/line level (0, -20, -40 dBu)
    • SPN1624:
    • 1-8 line level (0 dBu),
    • 9-12 mic/line level (0, -20, -40 dBu)
    • 13-19 line level (0 dBu)
    • 20-24 mic/line level (0, -20, -40 dBu)
    • Output Level: 0 dBu nominal, max 20 dBu
    • Output impedance: < 50 Ohms, all outputs, all attenuator settings
    • Dynamic range: 105 dB
    • THD + Noise: 0.01%
    • Programmable inputs:
    • SPN812: 15
    • SPN1612, 1624, 2412: 30
    • Frequency response: 20 Hz - 21 kHz ± 1 dB
    • Latency: Single PCB: 1.333 ms; System: 1.333 ms + 0.125 for each addn'l PCB
    • Monitor output: Any of the 48 final mixes
    • Output power: 50 mW


  • Item Includes:

    • 1 - Power Cord (Part #21499)
    • 2 - Cord Plug (Part #21558)
    • 20 - 5-position Plug (Part #21580)
    • 1 - USB Cable (Part #21713)
    • 2 - Patch Cable (Part #21802)
    • 1 - Adjustment Tool (Part #35679)
    • 1 - Software CD (Part #ASPENNETWIN)
    • 1 - Manual
