STRETCHERPRO-HD - Overview

Dynamic Real-Time Video Wall System

The Most Flexible Video Wall Solution

With the instant flexibility of SmartAVI's StretcherPro-HD, you can easily turn the walls of your business into a high tech video information center, at an affordable price. As you change the images on the fly your customers will appreciate this delightful experience. They will enjoy the outstanding quality and the mood it creates. While they're being entertained, the StretcherPro-HD lets you effortlessly program some advertising revenue into your bottom line.

The new StretcherPro-HD is capable of stretching any HD display over four screens, while maintaining any resolution up to 1920x1080 on each screen. This powerful new version stretches the video image in multiple ways including: Wall Mode (2x2), Dual Horizontal (2x1), Dual vertical (1x2), or Clone the image (1:1).

There are times when system architects do look beyond a 2x2 video display - shopping mall centerpieces, airport displays, concert events, theme park attraction queues, or nightclub venues, for example. StretcherPro-HD is expandable and versatile enough to meet the needs of systems integrators - from modest jobs to more complicated designs.

Multiple Layout Options

StretcherPro-HD supports any video input resolution from 800 x 600 up to 1920 x 1080 (high definition). The beauty of this unit is that regardless of the scaling - from one to all four screens - StretcherPro-HD maintains the original resolution quality of the image on all monitors, delivering a crisp, perfect image to your audience every time.

SmartAVI's StretcherPro-HD is the perfect entry-level display wall solution that has been aggressively priced within the market, without the complexity of external computer control or setup.

On Screen Display

All of the StretcherPro-HD's functions are controlled through On Screen Display (OSD). OSD gives users great flexibility and ease of use when looking to manage their video wall. By simply selecting from the SmartAVI menu, configuring the StretcherPro-HD on the fly is no hassle at all, with no additional screens or computers required to make changes. Users can also choose to operate the OSD through IR remote. RS-232 control is supported, as well.

  • Features:

    • 4 Screen Multilayout Digital Signage/Video Wall Controller
    • 1 HDMI Input, 4 HDMI Outputs
    • Internal EDID Tables
    • Learns any EDID Table
    • Resolutions up to 1920 x 1080
    • Output to 4 screens in clone, stretch horizontal or vertical modes
    • Requires no additional hardware or software
    • Multiple units can be linked for larger wall configurations
    • DVI-D with adapter
    • Supports IR & RS-232 control
    • HDCP Compliant

  • Specifications:

    • Video
    • Video Bandwidth: Single-link 340MHz [10.2Gbps]
    • Resolution HDTV: 480i,480p,720i,720p,1080i,1080p
    • PC Resolution: 800 x 600 up to 1920 x 1200
    • Input Video Signal: 1.2 volts
    • Input DDC Signal: 5 volts
    • Single Link Range: 1080p
    • Format: HDMI 1.4
    • DVI Compliance: Single-link DVI-D 2.0
    • HDCP Compliance: 1.0/2.0
    • Video Bandwidth: Single-link 340MHz [10.2Gbps]
    • Input Interface: (1) HDMI
    • Output Interface: 4 x HDMI
    • Connector: Type A [19-pin female]
      Control
    • Front Panel: Tact Switches w/OSD
    • RS-232: DB9 (female)
    • Remote: IR RC5
    • Additional: Optional Ethernet Control
      Power
    • Requirements: Internal 100-240 VAC
    • Power Supply Approvals: UL, CE, CSA, CEC, RoHS
      Mechanical
    • Height: 1.70 in. (1U)
    • Width: 17 in. (431.8 mm.)
    • Depth: 10.2 in. (259 mm.)
    • Weight: 4.05 lbs. (1.84 kg.)

  • APPLICATIONS

    :

    • Video Walls
    • Digital Signage Displays
    • Information Displays
    • Command Centers
    • Control Rooms
    • Simulation Systems
    • Restaurants and Clubs
    • Houses of Worship
    • Convention Facilities
    • Theme Parks
    • Resorts
    • Casinos
