Atlas SM8SUB70-B Surface Mount 8in Subwoofer System - Black

ITEM #: SM8SUB70-B MFG #: SM8SUB70-B

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$538.99

Our Price:

$432.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    SM8SUB70-B - Overview

    The SM8SUB70 8" subwoofer system is perfect for restaurants, bars, and high-fashion retail outlets. The system utilizes a 8" woofer housed in a 915 cubic inch multi-angle, flyable, wood enclosure system to provide extended low frequency response with a wide variety of mounting options. (Not for outdoor use!).

    Inserts are included for use with 1/4"-20 drop forge eyebolts, optional SM8CBKT-B /-W mounting bracket. An 18 dB/octave three-pole passive crossover eliminates the need for a separate electronic network or dedicated amplification to power the speaker. Its low crossover point (125Hz) nearly eliminates localization, allowing a designer to boundary-load the SM8SUB70-B near a wall or into a corner for maximum output, while maintaining even coverage throughout the space.

    A premium 70.7V transformer allows the SM8SUB70 to be paralleled with any 70.7V commercial audio system to provide extended low frequency response and more overall audio impact for foreground music systems. (Unit is also 8ohm compatible). Perfect for use with other SM series full range speakers Available In black (SM8CXT-B) or White (SM8CXT-W)

    • Features:

      • Attractive, yet Heavy-Duty Grille Assembly
      • Barrier Strip Input for 70.7/100V/8 Ohm or Parallel 4 Pole Speak-ONT Input for 8 Ohm Operation Only
      • Durable Black, Rough-Coat Finish
      • Fuse Protection for Driver
      • Includes Internal High Efficiency 60 Watt 70.7/100V Transformer (May be Bypassed for 8 Ohm Operation)
      • Multiple 1/4"-20 Inserts, Providing Fly Points for a Variety of Mounting Configurations
      • Optional Bracket for Wall Mounting
      • Unique Input Panel Allows Use of Standard 4" Square Box Cover (Raco 753 or eq.) for Applications Where Flex Conduit is Required for Termination
      • Omnimount™ Compatible (Not Sold by Atlas Sound)

    • Specifications:

      • Frequency Response: 55hz - 100hz
      • Speaker Type: Sub
      • Dispersion: Omni
      • Width: 10 5/8" (26.9875 Cm)

    • GTIN:

      0612079180769
