StarTech S3520BU33ER USB 3.0/eSATA Dual 3.5 Inch SATA III Hard Drive External RAID Enclosure w/ UASP & Fan - Black

ITEM #: ST-S3520BU33ER MFG #: S3520BU33ER

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the ST-S3520BU33ER

S3520BU33ER - Overview

The S3520BU33ER 2-Bay RAID Enclosure offers a high-performance external storage solution, enabling you to build a secure RAID array with two 3.5" SATA hard drives, with the option to connect it to your computer through either an available USB 3.0 or eSATA port.

For fast data transfers and efficient performance from your SATA III drives, the RAID enclosure supports full SATA III transfer speeds (up to 6 Gbps), as well as full USB 3.0 transfer speeds (up to 5Gbps). When connected through USB, the enclosure supports UASP, which offers performance up to 70% faster than conventional USB 3.0 when paired with a UASP-enabled host controller (see our performance below).

With support for JBOD, Spanning, RAID 0, and RAID 1,the enclosure offers several options that enable you to customize your drive arrangement based on your storage requirements.

To maximize both durability and reliability, the external RAID enclosure features high-quality aluminum construction with a built-in fan that helps improve ventilation and maintain a better operating environment for your drives.

The HDD enclosure offers a versatile solution for increasing the storage/backup capabilities of your computer, with support for large capacity hard drives (tested up to 4TB).

To ensure compatibility with your computer system, the S3520BU33ER supports all of the leading operating systems, including: Microsoft Windows (8/7/Vista/XP/Server 2008/Server 2003), Appler OSX (10.9/10.8/10.7/10.6), Linux, and Google Chrome OST.

It is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Improved Performance with UASP

UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.

  • Features:

    • UASP Support (Attached SCSI Protocol Specification Revision 1.0)
    • eSATA or USB Host Connection
    • Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps)
    • Hardware RAID
    • Plug-and-Play Compatible
    • Dual Drive Bay
    • Built-in Fan

  • Specifications:

    • Hardware
    • Chipset ID JM562
    • Compatible Drive Types (Type and Rate) SATA
    • Drive Installation Fixed
    • Drive Size 3.5in
    • Fan Bearing Type Ball Bearing
    • Fan(s) Yes
    • Fans 1 - 80 mm
    • Interface eSATA
    • USB 3.0
    • Number of Drives 2
    • Number of internal 3.5 inch bays 2

    • Performance
    • Hot Swap Capability Yes
    • Max Drive Capacity Currently tested with up to 4TB 7200 RPM hard drive
    • Port Multiplier Yes
    • RAID Yes
    • Supported RAID Modes BIG (Spanning or Concatenation)
    • JBOD - (Just a Bunch of Disks)
    • RAID 0 (Striped Disks)
    • RAID 1 (Mirrored Disks)
    • Type and Rate USB 3.0 - 5 Gbit/s
    • SATA III (6 Gbps)
    • UASP Support Yes

    • Connector(s)
    • Drive Connectors SATA Data & Power Combo (7+15 pin) Receptacle
    • Host Connectors eSATA (7 pin; Data) Female
    • USB 3.0 B (9 pin; SuperSpeed) Female

    • Software
    • Microsoft WHQL Certified Yes
    • OS Compatibility Windowsr 8/8.1 (32/64bit), 7 (32/64bit), Server 2008 (32/64), Vista(32/64), Server 2003 (32/64) XP(32/64), 2000
    • Apple Mavericks (10.9) OSX Mountain Lion (10.8), Lion (10.7), Snow Leopard (10.6)
    • Linux
    • Google ChromeT OS

    • Physical Characteristics
    • Color Black
    • Enclosure Type Aluminum and Plastic
    • Product Height 3.3 in [85 mm]
    • Product Length 6.9 in [176 mm]
    • Product Weight 21.9 oz [620 g]
    • Product Width 4.4 in [113 mm]

    • Indicators
    • LED Indicators 1 - Enclosure Power LED
    • 1 - Drive 1 Activity LED
    • 1 - Drive 2 Activity LED

    • Power
    • Center Tip Polarity Positive
    • Input Voltage 100 ~ 240 AC
    • Output Current 3 A
    • Output Voltage 12 DC
    • Plug Type M
    • Power Source AC Adapter Included

    • Environmental
    • Humidity 20%RH ~ 80%RH
    • Operating Temperature 5°C to 35°C (41°F to 95°F)
    • Storage Temperature -20°C to 50°C (-4°F to 122°F)

  • Warranty:

    • 2 Years

  • GTIN:

    0065030853613
