ST1216PRO - Overview

This high resolution StarTech ST1216PRO VGA splitter offers a practical solution for high-res multi-screen presentations, allowing a VGA video signal to be broadcast from a computer to up to 16 VGA monitors simultaneously.

The VGA splitter is ideal for classrooms, tradeshows, in-store displays or any application where high quality video on multiple monitors is required, supporting displays with up to 400 MHz of video bandwidth and high resolution applications up to 2048 x 1536.

To help ensure high quality VGA video even at longer distances, the high resolution VGA splitter features a built-in booster circuit that allows monitors to be located up to 210ft away from the host system.

Designed for simplicity and convenience, the VGA splitter offers easy plug and play installation; a completely hardware-based solution, the VGA splitter requires no software operation, saving both time and hassle.

Backed by our 2-year warranty and free lifetime technical support, this high-resolution VGA splitter lets you get the most out of your video content with quality construction you can depend on.

Applications
In-store product merchandising
Information booths/kiosks
Trade-shows

  • Features:

    • Compatible with VGA, SVGA and Multisync monitors
    • 400 MHz bandwidth provides brilliant 2048 x 1536 resolution
    • DDC,DDC2 & DDC2B compatible (on Video Out port 1)
    • Includes DC 7.5V power adapter and rack mounting brackets
    • Daisy chainable for almost unlimited expansion
    • Uses standard monitor extension cables (StarTech.com coaxial VGA cables recommended for best picture quality)

  • Specifications:

    • Connector(s)
    • 1 - Connector A: VGA (15 pin, High Density D-Sub)
    • 16 - Connector B: VGA (15 pin, High Density D-Sub)

      Hardware
    • Ports: 16
    • Daisy-Chain: Yes

      Packaging Information
    • Shipping (Package) Weight: 15.4 oz [435.0 g]
    • Package Length: 17.6 in [44.8 cm]
    • Package Width: 3.6 in [9.2 cm]
    • Package Height: 6.0 in [15.2 cm]

      Performance
    • Maximum Cable Length: 213.2 ft [65 m]
    • Maximum Analog Resolutions: 2048x1536 @ 60Hz
    • Bandwidth: 400MHz

      Physical Characteristics
    • Weight of Product: 5.2 oz [148.0 g]
    • Color: Silver
    • Product Length: 14.7 in [37.3 cm]
    • Product Width: 3.0 in [7.5 cm]
    • Product Height: 1.7 in [4.2 cm]

      Power
    • Power Source: AC Adapter Included
    • Output Voltage: 12V DC
    • Output Current: 1.2A
    • Power Consumption (In Watts): 14.4

  • Item Includes:

    • 16 Port Rack Mount VGA Splitter
    • Mounting Screws
    • Universal Power Adapter (NA/UK/EU)
    • Instruction Manual
    • 2 - Mounting Brackets

  • GTIN:

    0065030805292
