Tripp Lite INTERNET600U 600VA 300W UPS Desktop Battery Back Up Compact 120V USB RJ11 PC

INTERNET600U - Overview

• Features:

  • INTERNET600U standby UPS offers protection from blackouts, brownouts and surges on both AC and dialup modem lines
  • Provides seamless battery derived AC output during blackouts and severe brownouts so that connected equipment can be shut down without data loss
  • Built-in USB (HID compliant) interface port enables automatic system shutdown if power fails while the system runs unattended
  • PowerAlert software available via free download from http://www.tripplite.com, cable included
  • HID-compliant USB port also enables integration with built-in power management and auto shutdown features of Windows and Mac OS X


• Specifications:

  • Output Volt Amp Capacity (VA) 600
  • Output Watt Capacity (Watts) 300
  • Nominal Output Voltage(s) Supported 115V; 120V
  • Frequency Compatibility 60 Hz
  • Output Voltage Regulation (Battery Mode) 115V (+/- 5%)
  • Output Receptacles (8) 5-15R
  • UPS Output Receptacles (Surge Suppression Only) 4 UPS outlets, 4 surge-only outlets
  • Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)
  • Output AC Waveform (AC Mode) Sine wave
  • Output AC Waveform (Battery Mode) PWM sine wave
  • Rated input current (Maximum Load) 10A
  • Nominal Input Voltage(s) Supported 120V AC
  • UPS Input Connection Type 5-15P
  • Input Circuit Breakers 10A
  • UPS Input Cord Length (ft.) 6
  • UPS Input Cord Length (m) 1.8
  • Recommended Electrical Service 15A 120V
  • Input Phase Single-Phase
  • Half Load Runtime (min.) 9.9 min. (150w)
  • DC System Voltage (VDC) 12
  • Battery Recharge Rate (Included Batteries) NULL
  • Switches Combination switch controls on/off power status and self-test operation
  • Audible Alarm Audible alarm indicates power-failure and overload status
  • LED Indicators 2 LEDs indicate power status and overload/check battery status
  • UPS AC Suppression Joule Rating 420
  • UPS AC Suppression Response Time Instantaneous
  • UPS Dataline Suppression 1 line TEL/DSL (1 in / 1 out)
  • EMI / RFI AC Noise Suppression Yes
  • Installation Form Factors Supported with Included Accessories Tower; Ultra-compact desktop
  • Included Mounting Accessory Description Wallmount installation supported using keyhole mounting tabs
  • Primary Form Factor Desktop
  • UPS Power Module Dimensions (hwd, in.) 3.1 x 10.8 x 5.7
  • UPS Power Module Dimensions (hwd, cm) 7.8 x 27.6 x 14.6
  • UPS Power Module Weight (lbs.) 6.5
  • UPS Power Module Weight (kg) 3
  • UPS Shipping Dimensions (hwd / in.) 4.1 x 8 x 13
  • UPS Shipping Dimensions (hwd / cm) 10.4 x 20.3 x 33
  • Shipping Weight (lbs.) 7
  • Shipping Weight (kg) 3.2
  • UPS Housing Material ABS
  • Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius.
  • Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius.
  • Relative Humidity 0 to 95%, non-condensing
  • AC Mode BTU / Hr. (Full Load) 10.3
  • Battery Mode BTU / Hr. (Full Load) 194.3
  • AC Mode Efficiency Rating (100% Load) 0.99
  • Communications Interface USB (HID enabled)
  • PowerAlert Software Free download from www.tripplite.com
  • Communications Cable USB interface cable included
  • WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
  • Network UPS Tools Compatibility NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
  • Transfer Time 2-4 milliseconds
  • Low Voltage Transfer to Battery Power (Setpoint) 99
  • High Voltage Transfer to Battery Power (Setpoint) 139
  • Cold Start (Startup in Battery Mode During a Power Failure) Cold-start operation supported
  • Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS
  • UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI); ENERGY STAR Qualified
  • Product Warranty Period (U.S. & Canada) 3-year limited warranty
  • Product Warranty Period (Latin America) 3-year limited warranty
  • Product Warranty Period (International) 2-year limited warranty
  • Product Warranty Period (Mexico) 3-year limited warranty
  • Connected Equipment Insurance (U.S., Canada & Puerto Rico) $100,000 Ultimate Lifetime Insurance


• GTIN:

  0037332211033
