AV Tool AP-411 Lip Sync Corrector

ITEM #: TV1-AP-411 MFG #: AP-411

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$180.00

Availability: In Stock
iAvailability Description Popup


    AP-411 - Overview

    The AV Tool AP-411 Lip Sync Corrector is a compact device used to correct audio/video timing mismatches that result in the loss of synchronization of the two components of A/V program content. Since this problem is virtually always caused by the program's video component arriving after the audio component, the AP-411 Lip Sync Corrector provides up to 300 milliseconds of delay for the audio component to restore A/V synchronization to the program material.

    Excellent specification of >80dB S/N plus <-70dB of crosstalk and <0.01% Total Harmonic Distortion (THD-N) are coupled with a 48kHz sample rate to provide superior performance under demanding conditions. Inputs up to 2Vrms are accepted and the output level is a maximum of 2Vrms. The unit requires only 5VDC for operation and consumes only 0.5 watt of power. An AC Adapter is provided.

    • Features:

      • Resynchronizes program audio to video
      • Sample rate of 48kHz
      • Accepts Input levels up to 2V/rms
      • Provides Output levels to 2V/rms
      • >80db S/N, <-70dB Crosstalk, <0.01% THD-N


    AP-411 - Required Accessories
