Universal Audio 4-710d Four-Channel Twin-Finity Tone-Blending Mic Pre

ITEM #: UA-4-710D MFG #: 4-710D

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$2,499.00

Our Price:

$1,999.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


4-710D - Overview

Four Channels of Tone-Blending "Twin-Finity"Preamps and 1176-Style Compression with Built-In A/D Converters

The Universal Audio 4-710d is a boutique quality, four-channel microphone/line preamplifier with unique tube and solid-state tone blending capabilities - perfect for a wide range of microphone and instrument sources. This versatile multi-channel preamp offers selectable 1176-style compression circuitry on each channel, plus four additional line inputs feeding eight channels of pristine analog-to-digital conversion. Building upon UA's classic analog design approach, combined with smart modern features, the 4-710d is the most flexible preamp in the UA lineup.

At the core of the 4-710d are four channels of tone-blending "Twin-Finity" mic preamps with true-bypass 1176-style compression, including specially tuned "fast" and "slow" settings. Each of the four mic preamp channels allows for continuously variable phase-aligned tone, between a 100% tube and 100% solid-state signal path. Send and return jacks are available for external processing or signal access.

The eight analog inputs are digitized via ultra high-quality 24-bit A/D converters at selectable sample rates up to 192 kHz. Digital output is available via dual ADAT "lightpipe" or AES/EBU DB-25 connectors, facilitating integration with most popular audio interfaces.

  • Features:

    • Four TEC Award-winning 710 Twin-Finity microphone/line preamps, each featuring:
    • Phase-aligned tone-blending of tube and solid state circuits, creamy to crunchy
    • Newly designed 1176-style compression circuit per preamp channel
    • Backed by 1-Year limited warranty

  • Specifications:

    • Analog-to-Digital Conversion
    • Eight channels of high quality 24-bit A/D conversion:
    • Selectable sample rates up to 192 kHz
    • Digital output via dual ADAT optical and AES/EBU DB-25 connectors
    • 8-channel soft limiter (switchable for all channels)
    • Ultra-low jitter clock subsystem
    • LED metering array with clip/hold indicators
    • 75Ω BNC work clock I/O
    • Digital outputs anti-pop protection on power-up
    • Universal voltage internal power supply
    • Heavy-duty metal construction, two-space rack unit
    • One year warranty including parts and labor

  • GTIN:

    0819937000621
