Kramer VM-1120 1:20 Balanced Audio Mono Distribution Amplifier
  • Kramer VM-1120 1:20 Balanced Audio Mono Distribution Amplifier
  • Kramer VM-1120 1:20 Balanced Audio Mono Distribution Amplifier

Questions? Ask a Markertek Expert:
800-522-2025 Email

Kramer VM-1120 1:20 Balanced Audio Mono Distribution Amplifier

Manufacturer: Kramer

Item #: VM-1120   •   MFG #: VM-1120



List Price:$1,090.00
Our Price:$872.00

free ship


Availability: Direct Ship From Manufacturer
i
Item ships directly from the manufacturer. Normal delivery time is 2-7 business days and is subject to manufacturer availability. Need it sooner? Call 800-522-2025, or email Customer Service for expedited delivery options.


  • 2 - 7 Day Normal Delivery Time - Faster Shipping Options at Checkout or Call Us.


Share!





The VM-1120 is a high performance distribution amplifier for balanced mono audio signals on XLR connectors. It can be configured as a 1:10 distribution amplifier for stereo balanced audio signals.


  • Features

    • Grouped Audio Level Controls.
    • Dual Mode - Configure as 1:20 (mono) or 1:10(stereo) DA.
    • SN Ratio - 89.3dB.
    • Standard 19_h Rack Mount Size - 2U.
      TYPICAL APPLICATIONS:
    • Audio duplication and production studios, delivering undiminished quality duplicates.
    • Recording studios.
    • Broadcast studios for on-line signal distribution. 0

  • Specifications

    • INPUTS: 4 balanced audio + 4dBm/50kohm on female XLR connectors.
    • OUTPUTS: 20 balanced audio + 4dBm/50ohm on male XLR connectors.
    • MAX. OUTPUT LEVEL: 23.8 Vpp.
    • BANDWIDTH (-3dB): 100 kHz.
    • S/N RATIO: 89.3dB.
    • CROSSTALK: -78dB.
    • CONTROLS: Level (x4): - 0.7dB to + 5.1dB, mode selector switches.
    • COUPLING: DC.
    • AUDIO THD + NOISE: 0.081%.
    • AUDIO 2nd HARMONIC: 0.006%.
    • POWER SOURCE: 230 VAC (115 VAC U.S.A) 18 VA.
    • DIMENSIONS: 19 inch (W), 7 inch (D), 2U (H), rack mountable.
    • WEIGHT: 3.5 kg (7.7 lbs.) approx.
    • ACCESSORIES: Power cord.
