West Penn 25841 Plencon RG6 18 Gauge CATV Plenum Coaxial 1000 Ft Ivory

ITEM #: WP-25841-1000 MFG #: 25841

Primary Image
West Penn Wire Corp
Free Shipping with $49 Minimum Order

List Price:

$614.30

Our Price:

$608.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    25841 - Overview

    West Penn 25841 RG6/U - 1 Conductor 18 AWG Solid, 100% Al. Foil + 77% Al. Braid and an overall Plenum PVC Jacket. Indoor for Plenum:- CATV/MATV.

    • Features:

      • ASTM bare copper
      • Foam Teflonr insulation
      • Dual shield, BiFoil plus aluminum braid
      • Flexible plenum jacket
      • Standard spool size 1000 feet


    • Specifications:

      • Number of Conductors: 1
      • AWG Size: 18
      • Conductor Stranding: Solid
      • Conductor Type: Bare copper
      • Nominal DCR: 6.5 Ohm/1000f
      • Insulation Type: Foam FEP
      • Insulation Thickness: 0.17 in
      • Shield Type Overall: 100% Aluminum Foil
      • Shield Type: 2 Aluminum Braid
      • Nominal Impedance: 75 Ohm
      • Nom. Cap. Between Conductors: 16.2 pF/f
      • Nominal Velocity of Propagation (VP): 82 %
      • UL Flammability NFPA: 262 Plenum
      • Operating Range: -20 to 60 Deg C
      • UL Voltage Rating: 300


    • Applications

      :

      • Indoor for:
      • CATV
      • MATV


    • GTIN:

      0612825051084
