West Penn Wire 819 RG-59/U For HDTV/SDI Black Per Foot

Name: West Penn Wire 819 RG-59/U For HDTV/SDI Black Per Foot
Brand: West Penn Wire Corp
SKU: WP-819-BK
Price: 0.72 USD
Availability: InStock

ITEM #: WP-819-BK MFG #: WP-819-BK

West Penn Wire Corp

Lengths:

Lengths

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$0.72

Add to Wish List Leasing Options

Availability: In Stock

Report Lower Price Large Quantity Quote

Overview

Required Accessories

Recommended Accessories

Reviews

Attachments

Required Accessories

Recommended Accessories

WP-819-BK - Overview

West Penn Wire 819 is a low cost RG59 coaxial cable capable of carrying 3.0Gb/s SMPTE 292M signal up to 220 Feet and a 1.5Gb/s SMPTE 292M signal up to 310 feet.

The West Penn 819 is constructed with a 20 Awg solid center conductor and 100% Bi-Foil shield and a 95% Tinned Copper Braid. It has a PVC overall jacket and a 0.232" Outside Diameter.

Specifications:
- Conductor: 20 AWG Bare Copper
- Stranding: Solid .032"
- Insulation Material: Gas Injected Polyethylene
- Insulation Thickness: 0.143'' Nom.
- Shield: 100% Aluminum Foil + 95% Tinned Copper Braid
- Jacket Material: PVC
- Overall Cable Diameter: 0.233'' Nom.
- Approximate Cable Weight: 31 Lbs/1M' Nom.
- Flame Rating: UL1666 Vertical Shaft
- Plenum Version Part Number: 25819
- Belden 1505A Equivalent
GTIN:
0612825057932
