Magenta Research MG-AOC-882-100 DisplayPort 1.4 Active Plenum Optical Cable 328 Feet (100 Meter)

ITEM #: MGE-MGAOC882-100 MFG #: MG-AOC-882-100

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Magenta Research
Free Shipping with $49 Minimum Order

Our Price:

$1,220.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

MG-AOC-882-100 - Overview

The Magenta AOC-882 active optical cable provides a simple yet powerful solution for extending high resolution over long distances. This plug and play DisplayPort 1.4 cable supports up to 8K60 4:4:4 with no compression, signal loss or latency up to 328 feet (100 meters) and without the need for external power. The MG-AOC-882 features HDCP and EDID support.

  • Features:

    • Up to 328ft (100m)
    • No external Power required
    • Plug and Play
    • DisplayPort 1.4
    • HDCP support
    • EDID support
    • No signal loss
    • 8K2Kp60 down to 480i supported


  • Specifications:

    • Units: Transmitter (Source); Receiver (Sink)
    • Standards Compliance: DisplayPort 1.4 / HBR3, HDCP 1.4 / 2.2; Fully Supports bi-directional EDID and HDCP communication
    • Video Bandwidth: Supports up to 8.1 Gbps per lane, 32Gbps Total
    • Max Color Depth: 48bits
    • Maximum Resolution & Distance: 8K @ 60hz
    • O/E Converter: 4x 850 nm Multi-mode VCSELs 4x GaAs PIN Photo Diodes
    • Connector Type: 20 pin DisplayPort version 1.4
    • Cable Type: Hybrid cable, 4x fiber and 8x copper wire
    • Cable Length: 100 meters/328 feet (with +/-30cm tolerance)
    • Cable Outer Diameter: 4.8mm
    • Jacket Outer Material: Plenum
    • Cable Weight TBD
    • Cable Color: Black
    • Maximum Tensile Load: 30.5kg
    • Minimum Bend Radius: 48mm
    • Power Consumption: <0.5 watt each end
    • Power Supply: No external power required, powered from DisplayPort source device
