ZOOM R20 Multi-Track Recorder with Pre-Loaded Drum Loops/On-Board Editing/Built-In Effects

ITEM #: ZOOM-R20 MFG #: ZR20

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$449.99

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    ZR20 - Overview

    The ZOOM R20 is a multi-track recorder that redefines 'easy'. With a familiar touchscreen interface, it's insanely simple to track, edit and mix your songs, letting you focus on the music.

    The R20 has the best preamps and noise floor of any multi track recorder Zoom has ever designed. With six XLR inputs, two combo inputs, and 16 tracks of recording, the R20 is perfect for singer-songwriters to full bands.

    Improve your workflow with color-coded faders, gain dials, and touchscreen track regions, making sure you are always adjusting the correct channel.

    Polish your tracks and mixes with professional effects such as EQ, compression, and more. The R20 provides a full MFX processor compatible with Guitar Lab software.

    With 30 genres, 150 rhythm patterns and song form variations, it's hard to find a drummer this versatile. Plug in a MIDI keyboard via USB-C or use the touchscreen to add sonic textures with 18 built-in synth sounds from the R20's internal synthesizer. The R20 can import and playback standard MIDI files allowing you to import bass lines, melodies, piano parts, and more to use as backing tracks.

    You can use the R20 as an 8-IN/4-OUT or a 2-IN/2-OUT audio interface with PC, Mac and iOS. The R20 utilizes the Mackie control Protocol to allow you to use the faders and transport controls while recording with your computer and DAW.

    Use the optional ZOOM BTA-1 Bluetooth Adaptor to control the R20 wirelessly from your iOS device. This is also the first multi-track recorder that allows accessibility for the visually impaired, the R20 Control App features VoiceOver and VoiceOver Gestures.

    • Features:

      • 4.3" Full-color LCD touchscreen display
      • Easy-to-use DAW-inspired interface
      • Record up to 16 tracks (8 simultaneously)
      • 8 XLR mic preamps, including two mic/line/instrument combo jacks
      • Hi-Z available on input 1 and 48V phantom power available on Inputs 5-8
      • Onboard editing and built-in effects
      • Pre-loaded drum loops
      • Optional BTA-1 Bluetooth enables wireless control via the R20 Control App
      • USB-C audio interface (Multi Track Mode : 8-IN/2-OUT, Stereo Mode : 2-IN/2-OUT)
      • Records directly to SDHC cards up to 32GB and SDXC cards up to 1TB
      • New locking-type AC Adapter (ZAD-1220)
      • Up to 24-bit/44.1kHz audio in BWF-compliant WAV
      • Compatible with Guitar Lab software for Mac/Windows PC

    • Specifications:

      • Inputs
      • MIC/LINE (Mono) Connectors: 2x XLR/TRS combo jacks, 6x XLR
      • Input Gain: 6dB - 50dB
      • Input Impedance: XLR: 3.9kΩ TRS: 5.3 kΩ/1MΩ
      • Max Input Level: 4dBu (@0dBFS)
      • Phantom Power: 48V (INPUTS 5-8, switchable in pairs)
      • EIN: -121dBu or less (IHF-A) with 50dB/150Ω input
      • Frequency Response: -1.0dB: 20Hz - 20kHz

        Outputs
      • MASTER OUT Connectors: 2x TRS phone jacks (balanced)
      • Max Output Level: 14dBu
      • Output Impedance: 200Ω
      • PHONES Connector: 1x stereo phone jack
      • Max Output Level: 20mW + 20mW (into 32Ω load)
      • Output Impedance: 33Ω

        Recorder
      • Max Simultaneous Recording Tracks: 8
      • Max Simultaneous Playback Tracks: 16
      • Recording Format: 44.1kHz, 16/24-bit, mono/stereo WAV
      • Recording Media: 4GB-32GB SDHC cards, 64GB-1TB SDXC cards

        Effects
      • Max Number of Simultaneous Effects: 3 effects
      • Patch Memories: 50
      • Tuner: Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
      • Metronome Time Signatures: 3/4, 4/4, 6/8
      • Tempo Range: 40.0bpm - 250.0bpm
      • Rhythm Loops Sound Source Format: PCM
      • Number of Loops: 150
      • Synth Polyphony: 8
      • Synth Sound Source Format: FM
      • Number of Sound Types: 18 + PCM drum kit

        Misc
      • USB: USB 2.0 Type-C, 44.1kHz, 16/24-bit
      • Remote: Dedicated wireless adapter (ZOOM BTA-1)
      • Power: AC adapter (ZOOM ZAD-1220): 12 V/2.0 A
      • Power Consumption: 11W maximum
      • Dimensions (DxWxH): 8.11" x 14.88" x 2.28"
      • Weight: 2.93lbs

    • Item Includes:

      • 1x ZOOM R20 Multi-Track Recorder
      • 1x ZAD-1220 AC Adapter
      • 1x Quick Tour

    • GTIN:

      0884354025892
