Blustream UEX50B-KIT USB 2.0 Extender Set - 50m over a single CAT Cable

UEX50B-KIT - Overview

• Features:

  • Extends USB up to a distance of 50m over a single CAT cable
  • Supports USB 2.0 signal extension
  • Backwards compatible with USB 1.1 devices
  • Combined transmitted data bandwidth up to 480Mbps
  • 1 x USB Type-B on the Transmitter for connection to the Host device
  • 4 x USB Type-A hub on the Receiver for connection to peripheral devices
  • USB Type-A ports 1-2 support 5V 1A, with ports 3-4 supporting 5V 500mA
  • Simple plug and play, no driver installation or setup required


• Specifications:

  • UEX50B Receiver
  • CAT Connectors: 1 x RJ45 connector
  • USB Port: 1 x USB Type-B

    UEX50B Transmitter
  • CAT Connectors: 1 x RJ45 connector
  • USB Port: 4 x USB Type-A


  • Casing Dimensions (W x D x H ): 84mm x 60mm x 23.5mm (TX/RX)
  • Shipping Weight (kit): 0.5kg
  • Operating Temperature: 32°F to 104°F
  • Storage Temperature: -4°F to 140°F
  • Power Supply: 12V/2A DC


• Item Includes:

  • 1x UEX50B-TX
  • 1x UEX50B-RX
  • 1x USB Type-A to USB Type-B cable
  • 1x 12V/2A DC power supply
  • 2x Mounting kit
  • 1x Quick Reference Guide
