Crown CDI-2000 2-channel - 800W/4 Ohms - 70V/140V Audio Power Amplifier

ITEM #: CDI-2000 MFG #: CDI2000

Primary Image
Free Shipping with $49 Minimum Order

Our Price:

$2,009.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


CDI2000 - Overview

The Crown CDI-2000 is a 2-channel, 800W @ 4Ω, 70V/140V Power Amplifier that is part of the CDi Series of power amplifiers. These are professional power amps designed and built for installed sound applications. The CDi Series are all rugged and lightweight, and offer unmatched value in their class.
CDi-Series amplifiers feature an intuitive front-panel LCD screen to guide installers through their configurations. CDi amplifiers also offer onboard DSP for loudspeaker signal processing. Other features include a switch-mode universal power supply, useful function indicators, proportional-speed fan-assisted cooling, removable Phoenix-style inputs, barrier strip outputs for low-Z or 70V/140V loads, short-circuit protection and more.

  • Features:

    • Accurate, uncolored sound with very low distortion for the best in music and voice reproduction
    • Advanced protection circuitry guards against: shorted outputs, open circuits, DC, mismatched loads, general overheating, high-frequency overloads and internal faults
    • Extremely versatile; rated for 2Ω, 4Ω, 8Ω loads and 70V and 140V outputs
    • Intuitive front-panel LCD screen for quick, easy configuration
    • Switch-mode universal power supply
    • Onboard digital signal processing includes crossovers, EQ filters, delay, and output limiting
    • All products fill 2U rack spaces and weigh under 19lbs
    • Barrier strip outputs for low-Z or 70V/140V loads, removable Phoenix-style inputs

  • Specifications:

    • Channels: 2
    • Sensitivity (for full rated power @ 8Ω): 1.4V
    • Rated Power Output (per channel @ 4Ω): 800W Stereo
    • Signal-To-Noise Ratio (below rated 1kHz power @ 8Ω): 100dB (A-weighted)
    • THD: <0.5%
    • Damping Factor (20Hz - 400Hz): >500
    • Frequency Response (@ 1W, 20Hz - 20kHz): + 0dB, -1dB
    • Crosstalk (below rated power) 20Hz - 1kHz: >70dB
    • Input Impedance (nominal): 20kΩ balanced, 10kΩ unbalanced
    • IEC Power Connector: 15A
    • Operating Temperature: 32°F - 104°F
    • Ventilation: Flow-through ventilation from front to back
    • Cooling: Heat sinks and proportional-speed fan
    • Dimensions (HxWxD): 3.5" x 19" x 12.25"
    • Weight: 22lbs

  • Warranty:

    • 3-Year, No-Fault, Fully Transferable Warranty

  • GTIN:

    0691991013737
