LUX26-RM - Overview

Multi-color LEDs to set your display hue!

Masterclock's new 6-digit multi-color digital clock, the LUX26, includes an array of state-of-the-art features that outperform other digital clocks on the market. The 2.3" (5.8cm) kaleidoscopic LEDs can be configured to display an unlimited number of custom colors.

It can sync to a Network Time Protocol (NTP), Simple Network Time Protocol (SNTP), or time code* (*optional) source for accurate time, as well as be configured to any time zone offset or Daylight Saving Time parameters. Never miss out on a DST change again!

Its 6-digit digital display also has adjustable brightness capabilities and an auto-dimming option for all the many varied color choices in its repertoire. Included is a PM indicator and time format can be displayed as 12- or 24-hours in hour, minute, and second segmentation - hh:mm:ss. Date can be displayed as three variations - mm:dd:yy, dd:mm:yy, or yy:mm:dd. Visibility for this model reaches out to 100ft (30m).

  • Features:

    • 2.3" (5.8cm) 6-digit LED display
    • Create an unlimited number of custom colors
    • Syncs to any NTP or SNTP source for accurate traceable time
    • Optional time code input (IRIG-B, SMPTE 12M, 309M, 24/25/30fps, 29.97 drop frame)
    • Configures to time zone and Daylight Saving Time parameters
    • Retains time and date during loss of power and/or reference using a battery backed real-time clock (RTC) chip and maintenance-free rechargeable battery
    • WinDiscovery software utility included for easy configuration of clocks and generators within a network
    • Fully configurable network settings, including DHCP/STATIC IP
    • Configuration is saved to non-volatile memory and survives power losses
    • Password protection prevents unauthorized clock configuration tampering
    • Display time in 12- or 24-hr format - hh:mm:ss
    • Display date - mm:dd:yy, dd:mm:yy or yy:mm:dd
    • Configurable to alternate showing date and time automatically
    • Adjustable brightness levels with scheduled dimming & color change
    • Wall-mount bracket
    • PM indicator
    • Visibility: 100ft (30m)

  • Specifications:

    • Connectors: Ethernet RJ45, USB for configuration, 3-pin terminal block (differential time code input), BNC (single-ended time code input) optional.
    • Power: POE (Power over Ethernet IEEE802.3af), Power consumption < 15W.
    • Operating Parameters:
      - Operating Temperature: 32°F - 140°F (0°C - 60°C), Humidity: Up to 90% (non-condensing)
      - Storage Temperature: -40°F - 185°F (-40°C - 85°C), Humidity: Up to 90% (non-condensing @ 77°F [25°C]).
    • Physical:
      - Black powder-coated steel chassis
      - IP Rating: IP40
      - Size (HxWxD): 3.5" x 17" x 3" (8.9cm x 43.2cm x 7.6cm)
      - Weight: 8.0lbs (3.63kg)
    • MTBF: 86,700 - 100,000 hrs. All calculated using Fixed/Ground Mil HDBK 217F assumption
    • Compliance: FCC, ROHS, CE, ANSI
