RME Fireface 802 60-Channel Hi-Performance USB 2.0 or FireWire Audio Interface

ITEM #: RME-FF802 MFG #: FIREFACE 802

  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
free ship

List Price:

$2,499.00

Our Price:

$2,299.00

Availability: Ships Factory Direct, Typically in 3-10 Days
iAvailability Description Popup


    FIREFACE 802 - Overview

    The RME Fireface 802 renews RME's reputation built on the legendary Fireface 800. 60 channels of audio, high-end microphone preamps, reference class converters, a complete effects section and operation at up to 192 kHz are the base for many more features.

    A legend Reborn
    Ultra-low latency operation with USB or FireWire, combined with the legendary RME driver stability and maintenance. Active jitter suppression, individually switchable reference levels for all inputs and outputs, full stand-alone functionality, RME's unique DIGICheck metering and analysis toolbox, and identical operation on Windows PC and Mac.

    TotalMix FX, RME's digital high-end mixer and signal router, driven by two powerful DSPs, with integrated EQ, Dynamics and Reverb/Echo effects at up to 192 kHz, plus a built-in monitoring controller.

    The full-blown feature set also includes optional Class Compliant mode and operation with TotalMix FX for iPad, RME's app to fully control the 802 from the iPad, without any computer. The easy to use app includes metering for all 90 channels plus effects bus, different setup screens, and complete control of all features.

    The Fireface 802 is a highly integrated pro audio solution, a full-blown studio, all within a 19" enclosure. An interface designed for users who don't want to make compromises in sound, stability and ultra-low latency operation, and who long for an unrivaled professional feature set. Once again a milestone interface from RME, including the best of the best and even a bit more.

    Inputs and Outputs
    The Fireface 802 provides 60 channels of audio: 30 input and 30 output channels. All inputs and outputs can be used at the same time. Up to 12 analog and 18 digital channels can be recorded onto 30 tracks separately.

    • Features:

      • 12 x Analog I/O
      • 4 x Mic/Instrument
      • 2 x Phones Output
      • 1 x AES/EBU I/O
      • 2 x ADAT I/O
      • 1 x Word Clock I/O
      • 1 x MIDI I/O
      • FireWire or USB operation
      • Class Compliant Mode
      • TotalMix FX
      • ARC USB
      • RME USB 2.0

    • Specifications:

      • AD, Line In 1-8, rear
      • Resolution AD: 24 bit
      • Signal to Noise ratio (SNR): 113 dB RMS unweighted, 116 dBA
      • Frequency Response @ 44.1 kHz, -0.1 dB: 5 Hz - 20.8 kHz
      • Frequency Response @ 96 kHz, -0.5 dB: 5 Hz - 45.8 kHz
      • Frequency Response @ 192 kHz, -1 dB: 5 Hz - 92 kHz
      • THD: < -110 dB, < 0.00032 %
      • THD+N: < -104 dB, < 0.00063 %
      • Channel Separation: > 110 dB
      • Input: 6.3 mm TRS jack, electronically balanced
      • Input Sensitivity: 8 kOhm unbalanced, 12 kOhm balanced
      • Input Sensitivity Switchable to Lo Gain, +4 dBu, -10 dBV
      • Input Level for 0 dBFS @ Lo Gain: +19 dBu
      • Input Level for 0 dBFS @ +4 dBu: +13 dBu

        DA - Stereo Monitor Output Phones (9-12)
        As DA, but:
      • Output: 6.3 mm TRS stereo jack, unbalanced
      • Maximum Output Level at 0 dBFS, High: +16.8 dBu
      • Maximum Output Level at 0 dBFS, Low: +2 dBV
      • Output Impedance: 30 Ohm
      • AES/EBU: 2 x XLR, transformer-balanced, galvanically isolated, according to AES3-1992

        Microphone In 9-12, front
        As AD, but:
      • Input: XLR, electronically balanced
      • Input Impedance: 3.4 kOhm
      • Signal to Noise ratio (SNR): 112 dB RMS unweighted, 116 dBA
      • Gain Range: 54 dB
      • Maximum Input Level, Gain +6 dB: +10 dBu

        Instrument In 9-12, front
        As AD, but:
      • Input: 6.3 mm TS jack, unbalanced
      • Input Impedance: 800 kOhm
      • Signal to Noise Ratio (SNR): 112 dB RMS unweighted, 115 dBA
      • Maximum Input Level, Gain +6 dB: +21 dBu

        DA, Line Out 1-8, rear
      • Dynamic Range (DR): 115 dB RMS unweighted, 118 dBA
      • Frequency Response @ 44.1 kHz, -0.5 dB: 5 Hz - 20.8 kHz
      • Frequency Response @ 96 kHz, -0.5 dB: 5 Hz - 45 kHz
      • Frequency Response @ 192 kHz, -1 dB: 5 Hz - 89 kHz
      • THD: -110 dB, < 0.00032 %
      • THD+N: -104 dB, < 0.00063 %
      • Channel Separation: > 110 dB
      • Output: 6.3 mm TRS jack, servo-balanced
      • Output Impedance: 75 Ohm
      • Output Level Switchable Hi Gain, +4 dBu, -10 dBV
      • Output Level at 0 dBFS @ Hi Gain: +19 dBu
      • Output Level at 0 dBFS @ +4 dBu: +13 dBu
      • Output Level at 0 dBFS @ -10 dBV: +2 dBV

        ADAT Optical
      • 2 x TOSLINK I/O, format according to Alesis specification
      • Standard: 2 x 8 channels 24 bit, up to 48 kHz
      • Double Speed (S/MUX): 2 x 4 channels 24 bit 96 kHz
      • Quad Speed (S/MUX4): 2 x 2 channels 24 bit 192 kHz
      • Quad Speed Windows USB: 1 x 2 channels 24 bit 192 kHz

        SPDIF Optical (VIA ADAT2)
      • 1 x optical, according to IEC 60958

        Word Clock
      • BNC, switchable termination

        System Requirements
      • Windows XP SP2 or up, Intel Mac OS X (10.6 or up)
      • 1 x OHCI compatible FireWire Port 400 (1394a), FireWire 800 (1394b) via cable adapter
      • 1 x USB 2.0 port or USB 3.0 port
      • For USB: Computer with at least Pentium Core 2 Duo CPU

    • Item Includes:

      • 1x Fireface 802
      • 1x Cable USB 2.0, 1.8 m (6 ft)
      • 1x RME Driver CD
      • 1x Power cord
      • 1x Manual
      • 1x Optical cable (TOSLINK), 2 m (6.6 ft)

    • GTIN:

      4260123363055
