StarTech USBBT1EDR4 Mini USB Bluetooth 4.0 Adapter - 50m (165 Feet) Class 1 EDR Wireless Dongle

ITEM #: ST-USBBT1EDR4 MFG #: USBBT1EDR4

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$29.99

Our Price:

$26.32

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


USBBT1EDR4 - Overview

The USBBT1EDR4 USB to Class 1 Mini Bluetooth® Dongle lets you add Bluetooth wireless capabilities to a laptop or desktop computer through USB, with support for transfer distances of up to 50m (165ft). Compliant with Bluetooth 4.0 LE +EDR , the USB Bluetooth adapter offers data transfer rates up to 3 Mbps and low power consumption. This Bluetooth Smart Ready transceiver is an effective way to connect to a rapidly growing list of the Bluetooth Smart peripherals on the market, including the latest Apple® and Android™ smartphones and tablets. Bluetooth v4.0 also integrates added security for all transfers using 128-bit AES encryption. A conveniently portable device, this ultra-compact adapter is unobtrusive when connected to your laptop, so you won't have to remove it each time you store your laptop in a carrying case or bag. The adapter is also backward compatible with previous Bluetooth standards (v3.0, 2.0, 1.2 and 1.1) to ensure connectivity with all of your Bluetooth devices.

  • Features:

    • Bluetooth® 4.0 LE compliant Bluetooth Smart Ready transceiver
    • Class 1 device with 50m (165ft) effective range
    • Support for Enhanced Data Rate (EDR) with data transfer rates up to 3 Mbps
    • Low power consumption
    • Ultra-compact form factor
    • Backward compatible with Bluetooth v3.0, 2.0, 1.2 and 1.1 devices
    • Power / Linking / Standby LED indicator

  • Specifications:

    • Bus Type: USB 2.0
    • Chipset ID: CSR - CSR8510A06
    • Industry Standards: Bluetooth v4.0, v3.0, EDR
    • Frequency: 2.402-2.48GHz ISM Band
    • Max Distance: 50 m / 165 ft
    • Maximum Data Transfer Rate: 3 Mbps
    • Modulation: GFSK,p/4 DQPSK, 8DPSK
    • MTBF: 12,000 Hours
    • Connector Type(s): 1 - Bluetooth Class 1.0, 1 - USB Type-A (4 pin) USB 2.0 Male
    • OS Compatibility: Windows® XP, Vista, 7, 8, 8.1, 10, Windows Server® 2003, 2008 R2, 2012, 2016, Mac OS 9.x, 10.6 to 10.13
    • System and Cable Requirements: Available USB port
    • LED Indicators: 1 - Power / Standby / Link
    • Power Source: USB-Powered
    • Humidity: 0~75% RH
    • Operating Temperature: (14°F to 122°F)
    • Storage Temperature: (-4°F to 158°F)
    • Color: Black
    • Enclosure Type: Plastic
    • Product Height: 0.3 in
    • Product Length: 0.9 in
    • Product Weight: 0.1 oz
    • Product Width: 0.6 in

  • GTIN:

    0065030852920
