Compuvideo SVR-1780HDSD HD/SD-SDI Waveform Monitor
    Questions? Ask a Markertek Expert:
    800-522-2025 Email

    Compuvideo SVR-1780HDSD HD/SD-SDI Waveform Monitor

    Item #: SVR-1780HDSD   •   MFG #: SVR-1780HDSD




    SVR-1780HDSD is Digital 3Gb/s Multi-SDI Waveform Monitor with 6" Hi-Resolution CRT, NTSC & PAL, HD-SDI / SD-SDI Digital Signal Data Alarm Lock ID, External Reference Input for Timing and Genlock. Additionally SVR-1780HDSD includes HD/SD-SDI Digital Component Encoder, Re-Clocked and buffered HD-SD / SD-SDI output, Embedded HD/SD-SDI 16-CH Selectable Analog / AES / EBU Audio Out

    • Features

      • HD/SD-SDI Input
      • HD/SD-SDI Output
      • HD/SD-SDI Component HD/SD Analog Video Encoder
      • HD/SD-SDI Lock ID
      • HD/SD-SDI Audio Hi-Resolution Display
      • Accurate Y,Cb,Cr Color Space Conversion for Color RGB Gamut Display
      • Gamut / Color - Actual Hi-Resolution Real Time Parade Waveforms Display
      • External Reference Input
      • 16-CH Analog and AES / EBU Balanced Audio
      • Broadcast quality video and audio outputs to Component HD/SD Monitor or any other equipment
      • Hi-Resolution 6" CRT - Real Time Technology
    • Specifications

      • Formats 525i: 59.94 Hz
      • Formats 625i: 50 Hz
      • Formats 1080i: 60, 59.94, 50 Hz
      • Formats 1080p: 30, 29.97, 25, 24, 23.98 Hz
      • Formats 1080PsF: 30, 29.97, 25, 24, 23.98 Hz
      • Formats 720p 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 Hz
      • Standards: SMPTE 292M, 259M-C
      • HD/SD SDI Input: 1- BNC Input HD/SD-SDI
      • HD/SD SDI Out: 1- BNC Out Active Re-Clocked Buffered
      • Y, Pb, Pr Out to HD/SD Equip/Monitor: Encoded HD/SD-SDI to 3-BNC Component Output
      • Embedded Audio HD/SD-SDI: 16-CH Selectable Analog/AES/EBU Balanced Audio Out
      • External Reference: HD/SD-Analog
      • Power: Universal 100-240 V, 50/60Hz
      • Accessories: 1-HD/SD-SDI Cable, Power Cord
      • Weight / Size: 19 lbs / 6.5 (H) x 11.5 (W) x 15.5 (D)
      • Included: Metal enclosure / Tilt Stand / Handle
