SurgeX UPS-3000-LI-ISO 2760VA 4RU Line Interactive UPS with Isolation Transformer 208V/240V

ITEM #: SX-UPS-3000LIISO MFG #: 59300-68R

Primary Image
Free Shipping with $49 Minimum Order

Our Price:

$6,599.00

Availability: In Stock - Ships Factory Direct, Typically in 6 Business Days.
Please Email, Chat or Call (800) 522-2025
iAvailability Description Popup
  • Shipped truck freight.
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


59300-68R - Overview

Built with line interactive technology, the SurgeX UPS-3000-Li-ISO is a UPS and Isolation Transformer that provides a fast outage response time, 0.9 output power factor, true sine-wave output and a hot-swappable battery. When AC electricity fails, the UPS uses its internal, maintenance-free battery to supply reserved power to connected equipment.

The UPS also contains a low impedance isolation transformer that constantly filters and conditions the power supply. Preventing electrical noise from affecting performance, delivering clean, fully conditioned power to the source, and stopping harmful harmonics from reaching sensitive loads. It ensures a fully conditioned, safely managed interface between your equipment and the electrical supply

  • Features:

    • Line Interactive technology
    • Low impedance isolation transformer
    • 0.9 output power factor with true sine-wave output
    • Auto battery test and user hot-swappable battery
    • Advanced SNMP communication capability
    • User-friendly GUI interface and diagnostics

  • Specifications:

    • Power Rating (VA/Watts): 2760/2484
    • Inverter Waveform: Low Distortion Sine Wave
    • Transfer Time: 4ms. Typical
    • Frequency: 50/60Hz
    • BTU/Hr.: 446
    • T.H.D. Max. w/100% Resistive Load: <4% On Battery
    • Online Efficiency(w/o Charger): 95%
    • Input Voltage: 208
    • Input Current: 16.0A
    • Output Voltage: 230V and 115V
    • Output Current (VA/Watts): 12.0/11.5 and 24.0/21.6 Amps
    • Input Voltage Range (w/o Using Battery): 166V to 250V
    • Output Regulation (On Mains): +10%
    • Output Regulation (On Battery): +5%
    • Backup Time at Full Load (0.7 P.F): 6 Minutes
    • Floor Mountable: Yes (Optional)
    • Communications Interface: DB9, USB (SNMP Optional)
    • Shipping Weight: 142lbs (64.4kg)
    • Dimensions: 20.7" x 17.26" x 6.89" (525.77mm x 438.23mm x 175mm)
    • Output Receptacle:
      - 8x NEMA 5-20
      - 1x NEMA L6-20 Receptacles
    • PDU Compatible: Yes

  • Item Includes:

    • 1x UPS-3000-Li-ISO 2760VA Line Interactive UPS with Isolation Transformer

  • Warranty:

    • 1 Year Limited Warranty
