Universal Audio APX8 Apollo x8 Thunderbolt 3 Audio Interface (Rack/Mac/Win)

ITEM #: UA-APX8 MFG #: APX8

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$3,499.00

Our Price:

$2,799.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    APX8 - Overview

    Produce album-ready sounds in realtime.

    Produce album-ready sounds in realtime.
    Apollo x8 gives creators running bigger project and bedroom studios the same professional analog tones heard on your favorite records. With elite-class conversion and HEXA Core UAD plug-in processing, Apollo x8 is the only interface that lets you record through preamps from Neve, API, Manley, and more - with near-zero latency - giving you professional sound in a sleek rackmount Thunderbolt 3 audio interface.

    Hear Every Detail in your Recordings
    Apollo x8's proven A/D and D/A conversion gives you the same elite-class sound heard on thousands of hit songs and chart-topping albums. Widely praised for its open, natural sonics, Apollo's converters give you the perfect palette to paint your masterpiece.

    Record Synths and Vocals through Iconic Preamps
    With its four onboard Unison™ preamps, Apollo x8 is the only interface that lets you track in realtime through preamps and channel strips from Neve, Manley, API, and dozens more, giving you the same rich analog texture as the hardware used on decades of iconic music.

    • Features:

      • 18 x 24 Thunderbolt 3 audio interface
      • 4 Unison-enabled mic/line preamps
      • LUNA Recording System
      • Combine up to 4 Thunderbolt-equipped Apollos and 6 total UAD devices
      • Realtime UAD HEXA Core Processing
      • Runs UAD Powered Plug-Ins via VST, Audio Units, and AAX in all major DAWs
      • Selectable +24 dBu operation
      • Convenient front panel monitoring functions including Alt Speakers, Talkback mic, and assignable Dim or Mono

    • Specifications:

      • I/O Complement
      • Microphone Inputs: Four
      • High Impedance (Hi-Z): Instrument Inputs Two
      • Analog Line Inputs: Eight
      • Analog Line Outputs (DC coupled): Eight (ten including Monitor outputs)
      • Analog Monitor Outputs (DC coupled): Two (one stereo pair)
      • Headphone Outputs: Two stereo
      • ADAT Up to eight channels via dual I/O ports with S/MUX S/PDIF: One stereo input, one stereo output
      • Thunderbolt 3 Ports: Two
      • Word Clock: One input, one output

        Electrical
      • Power Supply: External AC-to-DC Power Supply, Level VI compliant
      • AC Input Connector Type: IEC Male
      • AC Requirements: 100V – 240V AC, 50 – 60 Hz
      • DC Connector Type: XLR 4-Pin Locking Male (Neutrik P/N NC4MDM3-H)
      • DC Requirements: 12 VDC, 6A
      • Maximum Power Consumption: 72W (30W typical)

        Mechanical
      • Temperature Range: 32° to 104°F (0° to 40°C)
      • Dimensions:
        Width: 19" (48.26cm)
        Height (1U rack space): 1.75 in (4.45cm)
        Depth, Chassis Only: 12.125 in (30.80cm)
        Depth, Including Knob & Jack Protrusions: 13.5" (34.29cm)
        Shipping Box (WxDxH): 23.5 x 17 x 7.5" (59.69 x 43.18 x 19.05cm)
      • Weight:
        Shipping Weight (with box & accessories): 16.6Lbs (7.52kg)
        Weight (bare unit): 9Lbs (4.08kg)

    • Item Includes:

      • 1x Apollo x8 Audio Interface Unit
      • 1x External Power Supply
      • 1x AC Power Cable (IEC), Region Specific
      • 1x Set of (4) Rack-Mount Screws
      • 1x Getting Started URL Card

    • GTIN:

      0819937002472
