Universal Audio Volt 876 USB Recording Studio - 24-in / 28-out Audio Interface / 8 preamps - MAC/WIN

ITEM #: UA-VOLT-876 MFG #: VOLT-876

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$1,249.00

Our Price:

$999.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


VOLT-876 - Overview

Meet legendary analog sound for the whole band.

Universal Audio Volt 876 USB Recording Studio gives serious music producers a next generation 32bit / 192kHz audio interface with eight onboard Vintage preamps and classic 1176 style compressors right on its front panel, providing big analog studio sound to every mic and instrument you connect.Built by the same team behind the legendary Apollo interfaces, Volt 876 delivers a beautifully integrated recording experience, including full recall of interface settings, mobile iPhone or iPad recording, an award winning suite of UAD plug ins and instruments, and UA's breakthrough LUNA Digital Audio Workstation with AI powered smart recording tools.

Record your Music with Best-in-Class 32-bit Audio
From the team that brought you the game-changing Apollo interface, Volt 876 delivers next-gen 32-bit/192kHz sound quality with eight preamps and compressors - perfect for recording larger groups - with more character and tone than any USB interface in its class.

Capture Legendary Sounds with Eight Vintage Mic Preamps
There's a reason UA's 610 tube mic preamp has been heard on records from Ray Charles to Van Halen to Adele - its warmth and presence are unmatched. Volt 876 gives you the same iconic preamp sound using selectable Vintage mode - UA's exclusive tube emulation circuitry that gives your sessions the sound of a studio classic.

Get 1176-Style Compression Tuned for Voice, Guitars, and More
Add album-ready punch and presence with Volt 876's eight onboard 76 Compressors - an innovative analog circuit inspired by UA's famous 1176 Limiting Amplifier. The 76 Compressor features presets to tame voice, guitars, synths, and drums (fast mode). So you can just plug in, pick a setting, and sound great.

All the Connectivity You'll Ever Need with 24 x 28 I/O
Volt 876 gives you 8 x 8 analog connections for mics, instruments, and studio gear, plus two front-panel mic / line inputs with switchable Hi-Z for easy D.I. recording. Need more? ADAT I/O connections let you link up to three Volt 876s to create a 24-channel recording system, or expand Apollo and other ADAT-equipped studios.

Use with LUNA for Analog Studio Sound and Smart AI-powered Tools
Volt 876 works with all major DAWs. But when you pair it with UA's LUNA DAW you get the incredible sound of an analog studio with powerful hardware-software integration, unlimited tracks, smart AI-powered tools - including "Hey Luna" Voice Control, Instrument Detection, and Tempo Listen - that make recording easier.

  • Features:

    • 24-in/28-out USB audio interface with eight preamps and cutting-edge 32-bit/192kHz audio conversion
    • Vintage Mic Preamp mode on every channel for recording your voice, guitar, synths, or band with the rich, full sound of an iconic UA 610 tube preamp
    • UA 76 Compressors on every channel to add clarity and punch to vocals, drums, instruments, and other sources with analog circuit based on UA's renowned 1176
    • Digitally-controlled mic preamps with Assistive Auto-Gain and full session recall with UAD Console app and LUNA Digital Audio Workstation
    • 16-in/16-out ADAT connectivity for digital expansion and linking of up to three Volt 876 interfaces to form the ultimate 24 x 28 recording system
    • Standalone ADAT mode to connect Volt 876 to third-party interfaces or Apollo over ADAT as an 8 x 8 I/O preamp expander
    • Onboard talkback microphone for effortless studio communication

  • Specifications:

    • Monitor Outputs: 2x stereo (Main and Alt. Monitors)- Main (Line Out 1-2), Alt (Line Out 3-4)
    • Headphone Output: 2x stereo
    • USB: 1x USB 2.0 port (USB Type-C connector)
    • MIDI: In, Out (2x 5-pin DIN connectors)
    • Digital/Optical: 2x in, 2x out
    • ADAT (S/MUX capable):
      - 16 channels @ 44.1kHz - 48kHz (fs1)
      - 8 channels @ 88.2kHz - 96kHz (fs2)
      - 4 channels @ 176.4kHz - 192kHz (fs3)
    • S/PDIF (Toslink): Stereo at all sample rates

      A/D - D/A Conversion
    • Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192kHz
    • Bit Depth: 32

      Microphone Inputs - Channels 1-8
    • Frequency Response: 20Hz - 20kHz, ±0.1dB
    • Dynamic Range (A-weighted): 116dB
    • THD + Noise (1kHz @ -1dBFS): -110dB (0.0003%)
    • Maximum Input Level: 14dBu
    • Input Impedance: 2kΩ
    • Available Gain (Digitally-controlled): 60dB
    • Phantom Power: +48V (switchable)
    • Connector Type: XLR Female, pin 2 positive

      Instrument Inputs - Channels 1-2
    • Frequency Response: 20Hz - 20kHz, ±0.04dB
    • Dynamic Range (A-weighted): 116dB
    • THD + Noise (1kHz @ -1dBFS): -87dB (0.004%)
    • Maximum Input Level: 12.5dBu
    • Input Impedance: 1MΩ
    • Available Gain (Digitally-controlled): 60dB
    • Connector Type: ¼" TS unbalanced

      Line Inputs - Channels 1-8
    • Frequency Response: 20Hz - 20kHz, ±0.05dB
    • Dynamic Range (A-weighted): 116dB
    • THD + Noise (1kHz @ -1dBFS): -108dB (0.0004%)
    • Maximum Input Level: 22dBu
    • Input Impedance: 10kΩ
    • Available Gain (Digitally-controlled): 60dB
    • Connector Type: ¼" TRS balanced or TS unbalanced

      Line Outputs - Channels 1-8
    • Frequency Response: 20Hz - 20kHz, ±0.1dB
    • Dynamic Range (A-weighted): 119dB
    • THD + Noise (1kHz @ -1dBFS): -111dB (0.0003%)
    • Maximum Output Level: 20.2dBu
    • Output Impedance: 100Ω
    • Connector Type: ¼" TRS balanced or TS unbalanced

      Headphone Outputs - Channels 1-2
    • Frequency Response: 20Hz - 20kHz, ±0.2dB
    • Dynamic Range (A-weighted): 116dB
    • THD + Noise (1kHz @ -1dBFS into >32Ω): -108dB (0.0004%)
    • Maximum Output Power into 32Ω: 225mW
    • Maximum Output Power in 600Ω: 35mW
    • Connector Type: ¼" TRS stereo unbalanced

  • Item Includes:

    • Included UA Software:
      - LUNA Digital Audio Workstation
      - Featuring Volt 876 remote-control integration and AI-powered tools
      - Teletronix LA-2A Tube Compressor
      - UA 1176 Classic FET Compressor
      - Pultec Passive EQ Collection
      - Century Tube Channel Strip
      - Oxide Tape Recorder
      - Verve Analog Machines Essentials
      - Pure Plate Reverb
      - Galaxy Tape Echo
      - PolyMAX Synth
      - Showtime `64 Tube Guitar Amp
    • Included 3rd Party Software:
      - Ableton Live Lite
      - Melodyne Essential by Celemony
      - Ampeg SVT-VR Classic Bass Bundle by Plugin Alliance
      - Marshall Plexi Classic Amp Bundle by Softube
      - Virtual Drummer DEEP by UJAM
      - Virtual Bassist DANDY by UJAM
      - LABS by Spitfire Audio
