JK Audio RIU-IP Remote IP Interface
The RIU-IP is a remote control interface designed for the new innkeeper 1x, innkeeper 2, and innkeeper 4 digital hybrids. This unit contains a web server which allows the user to send and receive control data through their web browser. RIU-IP can be connected to the user's computer NIC card for direct control, to a switch or hub for network control, or to an ethernet port with internet access for control from anywhere in the world.
Remote Control Capabilities:
- On-Hook and Off-Hook
- Confirmation of Off-Hook on On-Hook transition per line.
- Place call on hold or release hold.
- Dial (number) (line).
- Set Auto-Answer and ring count.
- Start and stop Conference (innkeeper 2).
- Adjust transmit and receive level per line.
- Test tone start/stop per line.
- Address book upload/download.
- Master Send configuration.
- Connects to the new innkeeper 1x, innkeeper 2, and innkeeper 4 Digital Hybrid
RJ45 Ethernet ports
- RS-232 remote control port with simple ASCII protocol
- No external power required
Specifications
- Control Connection: RJ-45 Ethernet port
- Digital Hybrid Connection: RJ-50
- RS-232 Serial Connection: DB-9
- Size: 5.7" x 3.5" x 1.125"
- Weight: 1 lbs.
