Accsoon CVSE CineView SE Multi-Spectrum Wireless Video Transmitter

ITEM #: ACC-CVSE MFG #: CVSE

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$748.75

Our Price:

$599.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


    CVSE - Overview

    Accsoon's most powerful, most advanced SDI TX/RX system to date is the latest addition to the CineView line. It is solidly built from aerospace-grade aluminum alloy and has a modern fanless design for silent running. The CineView SE is the ultimate affordably priced SDI and HDMI wireless on-set and on-location monitoring solution for productions of all sizes.

    Accsoon Dual-Band reliability with four antennas
    The CineView SE RX and TX units each have four removable antennas and a range of 1200ft using Accsoon's unique Dual-Band wireless technology. This transmits the same image on both 2.4GHz and 5GHz frequencies at the same time. The receiver then intelligently identifies interference as it combines the two signals together as needed into a complete single stream. This is inherently more stable than lower performing wireless systems that simply hop between frequencies. The result is super robust, near real time transmission of HD video and audio that can reach the length of a football field and is not plagued with drop-outs and black screens. Screen lag is almost imperceptible with new best-in-class latency at under 50ms.

    SDI and HDMI
    The transmitter has both SDI and HDMI inputs, while the receiver has SDI and HDMI outputs, both capable of frame rates up to 1080p 60fps. It even accepts SDI level A and B signals to cater for older professional cameras. This makes the CineView SE the perfect companion for every DP, director or camera operator thanks to its compatibility with a wide range of cinema, professional and mirrorless cameras.

    Smaller than ever
    CineView SE is even smaller and lighter than ever, with both transmitter and receiver weighing in at just 210g each. Both RX and TX units are around the size of a pack of cards, measuring 105mm x 66mm x 32mm, excluding antennas. This makes it much more compact than previous CineEye 2S Pro model, while at the same time enhancing performance.

    View on multiple monitors or iOS devices
    Like other CineView models, the CineView SE TX can be used with up to four other CineView RX units. It can also transmit to up to four iOS or Android devices running the Accsoon Go app, or any combination of RX units and smart devices totalling four.

    • Specifications:

      • Channels: 20
      • Frequency Range: 2412 to 2472 MHz, 5180 to 5580 MHz, 5660 to 5825 MHz
      • LUT Support: .cube
      • RF Power: 17dBm
      • Video Connectors: 1 x HDMI Input, 1 x SDI Input; 1 x HDMI Output, 1 x SDI Output
      • Video Format: 1080p at 23.98, 24, 25, 29.97, 30,50 59.94, 60 fps, 1080i 50, 59.94/50fps 720p/576p/480p
      • Wi-Fi: 2.4GHz & 5 GHz
      • Wireless Range: 1200' / 400 m (Line-of-Sight)

    • Item Includes:

      • 1x Accsoon CVSE CineView SE Multi-Spectrum Wireless Video Transmitter

    • Warranty:

      • 1 Year
