Hollyland MARS 4k UHD Wireless 5G Video Tx - SDI/HDMI 1.4 - 450-Ft/150m Loss Range w/ 0.06s Low Latency

ITEM #: HL-MARS4KTX MFG #: MARS 4K TRANSMITTER

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

Our Price:

$349.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


    MARS 4K TRANSMITTER - Overview

    The Hollyland Mars 4K wireless video transmission system is capable of a 450ft (150m) LOS range and ultra-low latency of 0.06s. The Mars 4K is designed to combine high performance and reliable quality at an affordable price. The Mars 4K supports 4K UHD video transmission at 30fps for the discerning videographer looking for high-resolution production capability. The Mars 4K achieves an incredible LOS range of 450ft (150m) and ultra-low latency of 0.06s. Its upgraded dual-core codec chip is capable of a data rate ranging from 8 Mbps to 20 Mbps, with 12 Mbps as the default. The Mars 4K supports HDMI and SDI input and output for expanded connectivity and compatibility. The SDI provides expanded frame rate flexibility for both broadcast and production frame rate (decimal-point frame rate) standards and compatibility through production and postproduction. The Mars 4K transmitter is compatible with up to two receivers or four mobile devices with the app installed. Up to four mobile devices with the app installed allow a maximum of four parties (such as the director, producer, light control personnel, and audio personnel) on the site to monitor the shooting at the same time. The Mars 4K is featured with superior corrosion and wear resistance for outstanding durability. With disassembly-free, bullet-styled antennas attached, the well-thought-out design form factor optimizes operational functionality for fast configurations.

    Please Note: This is the transmitter only! One transmitter can work with up to two receivers or four mobile devices with the app installed. Up to four mobile devices with the app installed allow a maximum of four parties (such as the director, producer, light control personnel, and audio personnel) on the site to monitor the shooting at the same time.

    • Specifications:

      • Interfaces:
        - HDMI Input (1.4b Type A Female)
        - 3G-SDI Input
        - 2x Antenna Interfaces (RP-SMA Male)
        - DC Input 2.0mm
        - USB Type-C OTG
      • Supply Interfaces: DC Power Input: 6-16V
      • USB Type-C Power Supply: 5V/2.5A (QC/DP not supported)
      • Battery Power Supply: 6-16V DC
      • Power Consumption: <8.5W
      • Weight: 7.87oz (223g)(without Antenna)
      • Dimension (LxWxH): 4.53" x 2.56" x 1.26" (115mm x 65mm x 32mm)

        Input/Output Video Formats
      • HDMI:
        - 720p 50/59.94/60
        - 1080i 50/59.94/60
        - 1080p 23.98/24/25/29.97/30
        - 1080p 50/59.94/60
        - 3840*2160 24/25/30
      • SDI:
        - 1080p 60/59.94/50 (Level A)
        - 1080p 60/59.94/50 (Level B)
        - 1080i 60/59.94/50
        - 1080p 30/29.97/25/24/23.98
        - 1080psf 24/23.98
        - 1080psf 30/29.97/25
        - 720p 60/59.94/50

      • Frequency: 5GHz
      • Modulation: 802.11n
      • Transmission Power: Maximum 21dBm
      • Transmission Latency: 0.06s
      • Transmission Bitrate: 8-20 Mbps
      • Transmission Distance: 450ft (150m)
      • Working Ambient Temperature: 14°F - 140°F (-10°C - 60°C)
      • Storage Temperature: -40°F - 140°F (-40°C - 60°C)
      • Bandwidth: 20 MHz

    • Item Includes:

      • 1x Transmitter
      • 3x Antenna
      • 1x DC Adapter
      • 1x User Guide

    • GTIN:

      0191460002908
