Stewart Audio AV-25-2 2-Channel Subcompact Amp - 25W x 2 at 8 Ohm

ITEM #: AV25-2 MFG #: AV-25-2

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$275.00

Our Price:

$234.00

Availability: In Stock
iAvailability Description Popup


    AV-25-2 - Overview

    The sub compact AV25 is built to meet the rigorous demands of high quality commercial, industrial and Pro Audio sound installations. Low cost, lightweight and convection cooling make this Class D amplifier flexible enough for a broad range of applications requiring quiet amplification. With an extremely compact form factor, the AV25 allows amplification to be located in places off limits to normal amplifiers without compromising sound or power. Like all Stewart products, the AV25 is designed for sonic accuracy, high efficiency and extended duty cycles. Our Signal Sense Power Technology (SSPT) ensures the amplifier is only powered when there is a signal present, saving energy and extending product life.

    Stewart Audio AV-25-2 Applications:
    Boardrooms & classrooms
    AV projection systems
    Lecterns and Podiums
    Plenum applications, UL 2043 rated
    Pole mounting option
    Fixed installations with amplifiers located in listening environment
    Applications where traditional amplifiers won't fit
    Behind flat screen televisions

    • Features:

      • Sub Compact 1/4 rack package
      • Two channel amplifier, optimized to drive 4 Ohm and 8 Ohm loads
      • Music and fire alarm muting
      • Clean full-range dynamic power
      • Signal Detect trigger for sleep & wake up
      • Multiple mounting options
      • External inline power supply
      • Made in the USA

    • Specifications:

      • 4 Ohm Stereo Power: 35W
      • 8 Ohm Stereo Power: 25W
      • Frequency Response (+0, -3dB, 1W): 30Hz - 20kHz
      • Power Bandwidth (+3, -3 dB): 30Hz - 30kHz
      • THD+N: <.1%
      • Signal to noise ratio: >100dB
      • External Mute: Contact Closure
      • Slew Rate: 30V/microsecond
      • Input Sensitivity: .5V (-3 dBV)
      • Standard Voltage Gain: 28X (26.5dB)
      • Input Impedance (Balanced/Unbalanced): 20k Ohm/10k Ohm
      • Standby, Idle Current Draw, 1/8 Power Draw: 0.005/0.01/0.15 Amps
      • Class: D
      • Input Connectors: Euro Block
      • Output Connectors: Euro Block
      • Power Supply: External in-line 48VDC (Included)
      • Cooling: Convection-Cooling (No fans)
      • Controls: Level
      • LED Indicators: Power, Signal Present, & Clip
      • Construction: Aluminum Chassis
      • Dimensions (H,W,D): 1.25"H x 4.35"W x 3.2"D
      • Weight: <.37 lbs (0.16kg)
      • Warranty: 3 years
      • Plenum Rating: UL 2043 Approved

    • Warranty:

      • 3 years
