Blonder Tongue NXG-SDI4 4 Channel SDI HD Encoder Module - Supports 4 HD-SDI or SD-SDI Inputs

NXG-SDI4 - Overview

• Features:

  • Encode SD-/HD-/3G-SDI sources for custom IP & RF distribution
  • 4 channels of locally sourced content via 4 SDI inputs
  • Encoding to H.265 (HEVC), H.264 (AVC), or MPEG-2
  • Dolbyr Digital Audio (AC3), AAC, and MP3 support
  • High video encoding quality levels at low bit rates


• Specifications:

  • Inputs
  • Connectors: 4x BNC SDI
  • SD-SDI: Bit Rate 270 Mbps, Video Resolution - 480i (59.94, 60 FPS);
  • HD-SDI: Bit Rate 1.485 & 1.485/1.001 Gbps. Video Resolution - 720p (29.97, 30, 59.94, 60 FPS); 1080i (59.94, 60 FPS); 1080p (29.97, 30, 59.94, 60 FPS)
  • 3G-SDI: Bit Rate 2.97 & 2.97/1.001 Gbps, Video Resolution - 1080p (29.97, 30, 59.94, 60 FPS), Level: A/B
  • AUDIO: Input Format PCM Raw (L-PCM, IEC-60958 @ up to 192 kHz)

    Outputs
  • UDP: SPTS to NXG Mainframe Backplane
  • TS Format: ISO 13818-1 SPTS on UDP/IP
  • Video Format MPEG-2; H.264 (AVC); H.265 (HEVC)
  • Video Resolution: 1080p (29.97, 59.94 FPS); 1080i (59.94 FPS); 720p (29.97, 59.94 FPS); 480p (29.97, 59.94 FPS); 480i (59.94 FPS)
  • Video Bitrate: 2 Mbps to 19 Mbps (0.1 Mbps increments)

    Alarms & Monitoring
  • Front Panel 1x Status LED (Bicolor)

    Audio
  • Audio Format Dolby® AC3, AAC, MP3
  • Audio Bit Rates 128, 192, 256 Kbps

    General
  • Dimensions (W x H x D): 1.15 x 7.0 x 15.5 in
  • Weight: 2.0 lbs
  • Power: DC via NXG Mainframe Backplane
  • Power Consumption: 20 W
  • Operating Temp.: 32 to 122 °F
  • Storage Temp.: -13 to 158 °F
  • Operating Humidity: 0 to 95% RH @ 35 °C max, non-condensing


• Item Includes:

  • 1x Blonder Tongue NXG-SDI4 4 Channel SDI HD Encoder Module - Supports 4 HD-SDI or SD-SDI Inputs
