    CA2250 - Overview

    The Cloud CA Series is a range of versatile multi-channel audio power amplifiers of advanced design, able to drive low impedance loudspeakers, or high impedance (100 V-line or 70 V-line) loudspeaker distribution systems directly. They are ideal for sound reinforcement applications in the retail, leisure, hospitality, commercial or industrial sectors.

    Model CA2250 can deliver a maximum of 500 W of audio power, which may be similarly shared between its two channels.

    Particular design attention has been paid to the amplifiers' energy efficiency. The Class D output stages dispense with line output transformers, and consequently offer great savings in weight and size over earlier designs. An automatic, two-stage power-down feature (APD) resulting in power consumption of less than 2.5 W. The amplifiers also include a remote standby/wake up function, enabling them to be placed into standby mode - and subsequently powered up again - by a simple external contact closure. The APD feature can be disabled by a rear panel DIP switch.

    Safety features of the design include output DC detection, overcurrent protection, and thermal monitoring. A switch on delay provides loudspeaker protection at power-up. All models use variable–speed forced-air cooling.

    • Features:

      • Output stage can drive 70 V/100 V-line systems directly (transformerless), or low impedance loudspeakers (≤4 ohms)
      • Output mode selectable per-channel
      • Balanced line level inputs
      • Per-channel output level controls
      • Per-channel rear panel input switches for input routing, high or low impedance operation, 70 V/100V -line selection and high-pass filter
      • Automatic Power Down: <2.5 W power consumption with all channels quiescent
      • Remote Power control input
      • Global disable of APD function
      • Variable speed forced-air cooling
      • Thermal protection, overcurrent limiting and DC offset protection
      • Switch-on delay for speaker protection during power-up
      • Universal PSU - operates from 100 to 240 VAC

    • Specifications:

      • Performance
      • Output Power: Total output power 500 W, both channels
      • Outputs: Low-impedance: 4 ohms or 8 ohms (selectable), High-impedance: 70 V or 100 V (rms)
      • Frequency Response: 20 Hz to 20 kHz, +0 dB/-1 dB
      • High Pass Filter: -3 dB @ 65 Hz via rear panel switches
      • Distortion: 0.019%THD+N @1 kHz, 1 dB below rated output
      • Noise: -94 dBr, 22 Hz to 22 kHz, relative to full power
      • Crosstalk: Ch1 to Ch2: < -98 dB @1 kHz, -79 dB @10 kHz, Other channel combinations: -107 dB @1 kHz, -98 dB @10 kHz (typical)

        Inputs
      • Connectors: 3-pole 3.5 mm-pitch plug-in screw-terminal connectors
      • Sensitivity: 0 dBu (0.775 Vrms)
      • Input Impedance: 10 kohms (balanced); 5 kohms (unbalanced)

        General
      • Output connectors: 2-pole 5 mm-pitch plug-in screw-terminal connectors
      • Power input: 85 to 265 V AC, 50 to 60 Hz
      • Mains protection Internal fuses: 1 x 250 V fuse
      • Normal operating temperature: 0 °C to 35 °C (Note performance and specifications cannot be guaranteed outside this range)
      • Power Consumption: Standby & APD: 0.795 W (12.43 VA) / Mute: 11.24 W (21.09 VA) / Idle: 17.07 W (28.13 VA) / 1/8th power: 88.33 W (105.8 VA) / 1/3rd power: 200.9 W (213.5 VA)
      • Heat loss: Standby & APD: 2.9 kJ/hr (2.7 BTU/hr) / Mute: 40.5 KJ/hr (38.4 BTU/hr) / Idle: 61.5 kJ/hr (58.3 BTU/hr) / 1/8th power: 91.7 kJ/hr (87.0 BTU/hr) / 1/3rd power: 122.5 kJ/hr (116.1 BTU/hr)
      • Amplifier Protection: Overcurrent, DC, Thermal monitoring, Switch-on delay
      • Status Indicators: Power applied, Protection active, Signal peak, and Signal present
      • Cooling: Variable speed fan
      • Dimensions (W x H x D): 19" x 3.46" x 9.11" / Shipping: 23.9" x 6.5" x 22"
      • Weight: 10.1lb

    • Item Includes:

      • 1x Cloud Electronics CA2250 2-Channel Audio Amplifier 250WPC @ 4 Ohms or 70/100v
