Defender DEF-85002 3 Heavy Duty Wide 3-Channel Cable Protector - Yellow/Black - 39x24x3 Inches / 48lbs

85002 - Overview

• Features:

  • Yellow polyurethane lid with high warning effect and secure closure
  • Patented, self-cleaning lid hinge
  • 3 channels: 1 channel 1.77" x 1.96", 2 channels 2" x 1.9"
  • Load capacity approx. 5 t / 9.8" x 11.8"
  • Fire protection class E according to DIN EN 13501-1 (B-s1 pending)
  • Resistant to oil, petrol and short-term contact with solvents
  • Dimensions 39x24x3 Inches / 48lbs
  • Reliable protection for cables and personnel for indoor and outdoor use
  • Curves, end ramps, and connector plugs are available as accessories
  • TUV SUD certified


• Specifications:

  • Product type: Cable Protectors
  • Type: 3 Channels
  • Width: 23.8"
  • Height: 2.95"
  • Length: 39.5"
  • Channels: 3
  • Width channel 1: 2"
  • Height channel 1: 1.9"
  • Width channel 2: 1.7"
  • Height channel 2: 1.9"
  • Width channel 3: 2"
  • Height channel 3: 1.9"
  • Material: Polyurethane
  • Max load: Approx. 5 t on a surface area of 9.8" x 11.8"
  • Chemical resistance: Oil-resistant, Petrol-resistant, Short-term contact with solvents
  • Hardness range: 88 Shore ± 4 Shore
  • Fire protection class: B2
  • Temperature range: -40 to 158°F
  • Weight: 48lbs


• Item Includes:

  • 1x Defender DEF-85002 3 Heavy Duty Wide 3-Channel Cable Protector - Yellow/Black - 39x24x3 Inches / 48lbs


• Warranty:

  • 5 Years
