D-Link DGS-1100-08P 8-Port Gigabit PoE Smart Managed Switch

ITEM #: DLNK-DGS-110008P MFG #: DGS-1100-08P

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$129.99

Our Price:

$99.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


    DGS-1100-08P - Overview

    Advanced Security Features
    The DGS-1100 series' (DGS-1100-08P) web user interface gives administrators an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), and link aggregation(static). With powerful security features including IGMP snooping, Static MAC, and Storm Control, these smart managed switches are a versatile solution for deployments that require easy to configure functionality without added complexities.

    Simplify Network Management
    D-Link's free Network Assistant (DNA) displays all your connected devices and makes first-time configuration a breeze. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools.

    Full PoE Support
    Selected models in the DGS-1100 Series support Power over Ethernet on copper access ports. Power over Ethernet greatly simplifies the installation of PoE-enabled devices such as VoIP phones and IP cameras in remote locations with no immediate access to a power outlet.

    Easy Troubleshooting
    The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily. Loopback Detection detects loops created by a specific port and automatically shuts down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.

    Green Technology
    D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE (excluding DGS-1100-05PD and DGS-1100-08P models).

    TAA Compliant.

    • Features:

      • TAA Compliant
      • 8 x 10/100/1000BASE-T PoE ports
      • Supports IEEE 802.3at PoE
      • Compact design for convenient placement
      • Fanless design for silent operation
      • Innovative D-Link Green energy saving features
      • Complete web interface for comprehensive switch management
      • Web UI - Easy to use web interface to access management features.
      • VLANs - Segment your network into VLANs.
      • Surveillance Mode Interface - Get a snapshot of your security topology in an instant.

    • Specifications:

      • 1000Base-T PoE Interface: 8
      • Auto MDI/MDIX: Yes
      • Switching Capacity: 16 Gbps
      • Max. Packet Forwarding Rate: 11.9Mpps
      • Dimension: 5.7 inch x 3.22 inch x 1.10 inch / 171 x 97.8 x 28.6 mm
      • Weight: 1.10 lbs / 0.433kg
      • Operation Temperature: 0-40°C
      • Storage Temperature: -40 - 70 °C
      • Operation Humidity: 0%-90% RH
      • Storage Humidity: 0%-95% RH
      • Operating Altitude: 2000m
      • Maximum Power Consumption: 4.6 W (PoE off) 77.9W (PoE on)
      • Power Input: AC:100 ~ 240 V (54V/1.574A power adapter
      • Packet Buffer Size: 1.5 Mbits
      • FAN: Fanless
      • Maximum PoE Budget: 64 W

    • GTIN:

      0790069453311
