Genelec 8010AP 3 Inch Bi-Amplified Active Monitor - Producer Black Finish

ITEM #: GNC-8010AP MFG #: 8010AP

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$395.00

Our Price:

$350.00

Availability: In Stock
iAvailability Description Popup


    8010AP - Overview

    The Genelec 8010AP is a 3 inch, black bi-amplified active monitor. Designed for simplicity, the 8010A is as comfortable in a hotel room, a broadcast van or a small studio, with dedicated mounting accessories for each application. Each active monitor comprises balanced XLR inputs, a 3 inch woofer, a 3/4 inch tweeter and two efficient Class D power amplifiers. Genelec Intelligent Signal Sensing (ISS™) circuitry is also included, ensuring that when your system is not in use, your monitors switch into an environmentally friendly, power-saving stand-by mode. Wherever you work, the 8010A is your ideal travelling companion.

    • Specifications:

      • System Specs
      • Lower Cut-Off Frequency, -6 dB: < 67 Hz
      • Upper Cut-Off Frequency, -6 dB: > 25 kHz
      • Free Field Frequency Response (± 2.5 dB): 74 Hz-20 kHz
      • Max. Short Term Sine Wave Acoustic Output On Axis In Half Space, Averaged From 100 Hz to 3 kHz: ≥96 dB SPL at 1m distance, ≥102 dB SPL at 0.5 distance
      • Maximum Long Term RMS Acoustic Output In Same Conditions With IEC Weighted Noise: ≥91 dB SPL
      • Maximum Peak Acoustic Output Per Pair On Top Of Console, @ 1m Distance With Music Material: ≥105 dB
      • Self Generated Noise Level In Free Field @ 1m on axis (A-Weighted): ≤5 dB
      • Harmonic Distortion At 80 dB SPL @ 1m On Axis Freq 70 - 400Hz: < 3%
      • Harmonic Distortion At 80 dB SPL @ 1m On Axis Freq >400Hz: < 0.5%
      • Bass: 76mm (3 in) cone
      • Treble: 19mm (3/4 in) metal dome
      • Weight: 1.5kg (3.3 lb)
      • Height Including Iso-Pod™ Table Stand: 195mm (7 11/16 in)
      • Height Without Iso-Pod™ Table Stand: 181mm (7 1/8 in)
      • Width: 121mm (4 3/4 in)
      • Depth: 115mm (4 1/4 in)

        Crossover Specs
      • Input Connector XLR Female 7 kOhm: pin 1 gnd, pin 2 + pin 3 -
      • Input level for 100dB SPL OutpLevel control range relative to max Output: -10dB (Sensitivity -10 dB on) ut At 1m: -6 dBu (Sensitivity -10 dB off)
      • Desktop Control Operating Range: 0 to -4 dB @ 200 Hz
      • Crossover Frequency, Bass/Treble: 3.0 kHz
      • Bass Tilt Control Operating Range In -2dB Steps: 0 to -6 dB @ 100 Hz

        Amplifier Specs
      • Bass amplifier power with an 8 Ohm load: 25W
      • Treble amplifier power with an 8 Ohm load: 25W
      • Amplifier System Distortion At Nominal Output THD+N: < 0.08 %
      • Mains Voltage: 100 - 240V AC
      • Voltage Operating Range: ±10 %
      • Power Consumption: Standby <0.5W, Idle 5W, Full output 30W

    • GTIN:

      6438128010948
