HuddleCamHD HC20X-SIMPLTRACKLITE SimplTrack Lite Auto-Tracking PTZ Camera - NDI/HX/USB 2.0/IP/SDI & HDMI Compatible

ITEM #: HC20XSIMPLTRACKL MFG #: HC20XSIMPLTRACKL

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the HC20XSIMPLTRACKL

HC20XSIMPLTRACKL - Overview

The HuddleCamHD SimplTrack Lite makes it easier than ever to deliver high-quality conferences or lectures with no camera operator - or expertise - required.
Smooth, automatic motion tracking up to 55ft away with focus up to 20X in 1080p at 60fps (30fps USB) with up to 270° rotation and 59.5° FoV
True plug and play: Use the included USB 2.0 cable to connect to any computer and start auto-tracking
Set and forget presets: Want to limit your tracking range? Set preset zones to keep the camera centered on whiteboards, conference tables and more

With a broad range of output options, including NDI®|HX, USB 2.0, IP, SDI, and HDMI compatibility, the SimplTrack Lite is easy to set up and can integrate seamlessly with your current system.
Compatible with most videoconferencing, streaming, lecture capture and learning management system platforms
Built-in 3.5mm headphone jack can be connected to any external microphone
Included dedicated management software allows for remote operation from any Windows PC, anywhere on the network

The SimplTrack Lite gives you flexible options for nearly any indoor setting, even without a dedicated PC.
Featuring PoE (802.3af), plus multiple mounting configurations available to meet the needs of any indoor setting, including inverted mounting
Capture subjects near or far with automatic tracking distance of up to 55ft, with 59.5° FoV and 270° rotation
Want more control? Enable Manual Mode via IP or included RS-232 cable to operate the SimplTrack Lite with included IR remote, a PTZ camera joystick controller, or camera control apps

  • Features:

    • 20X Optical Zoom
    • Motion & Facial Framing
    • RSTP / RTMP Streaming
    • Multiple Video Outputs
    • 1080p@60 FPS SDI Feed
    • 1080p@60 FPS IP Feed
    • 59.5° Field of View
    • Software Interface
    • Supposed VISCA Protocol & VISCA over IP
    • Photobooth Functionality
    • Preset Zones
    • All-in-One Solution
    • Dedicated Management Software

  • Specifications:

    • Image Sensor & Lens
    • Video Sensor: 1/2.8" CMOS, 2.14 Mega Pixel
    • Frame Rate: 60fps @ 1920x1080p
    • Lens Zoom: 20X Optical, f=4.7-94mm
    • Field of View: 2.9° (tele) to 59.5° (wide) Horizontal
    • Min Lux: 0.5 lux

      Pan / Tilt Movement
    • Pan Movement: ±170°
    • Pan Speed: 0.1° to 120° /s
    • Tilt Movement: +90° to -30°
    • Tilt Speed: 0.1° to 90° /s
    • Presets: 64 Presets

      Electrical Index Network 10/100
    • Power Supply: 12V DC 2.5A
    • Input Power: 20W (Max)
    • PoE: PoE (802.3af) Supported

      Physical Specifications
    • Material: Aluminum, Plastic
    • Color: Gray
    • Dimensions (WxDxH): 8.31 x 5.47 x 8.19" (211 x 139 x 208mm)
    • Weight: 2.64Lbs (1.2kg)
    • Working Environment: Indoor
    • Operating Temperature: 32° to 104°F (0° to 40°C)
    • Storage Temperature: -4° to 140°F (-20° to 60°C)
    • Humidity Range: 10% - 80%

  • Item Includes:

    • 1x 20X SimplTrack Lite Camera
    • 1x Power Supply
    • 1x IR Remote
    • 1x RS-232 Control Cable
    • 1x USB 2.0 Cable 3m / 9.8feet
    • 1x Quick Start Guide

  • Warranty:

    • 3-Year Warranty

  • GTIN:

    0840170500517
