JBL SRX915M 2-Way High Output 15-Inch Powered Multi-Purpose Speaker - 90 x 60

ITEM #: JBL-SRX915M MFG #: JBL-P3363MX

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$2,750.00

Our Price:

$1,899.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


JBL-P3363MX - Overview

The JBL SRX915M is a high-output, multi-purpose, two-way 15" powered point-source loudspeaker designed for applications that require greater low-frequency extension and increased headroom. It is ideally suited for use as a main PA or as a high-performance stage monitor. When deployed as a monitor, the enclosure's multi-purpose design provides a 45° monitor angle in a low-profile package.

Multiple M10 QuickLink suspension points support quick and secure integration with a variety of dedicated accessories for both portable and installed sound applications. Integrated DSP and amplification provide a true plug-and-play experience, ensuring consistent, optimized performance anywhere in the world.

JBL transducers and proprietary Progressive TransitionT waveguides deliver outstanding fidelity and best-in-class SPL from an enclosure of this size. A full- featured software suite provides comprehensive control and monitoring across Windows, macOS, and iPadOS platforms.

  • Features:

    • Single 15" low-frequency driver and neodymium 1.5" annular-diaphragm compression driver
    • 275F woofer employs JBL's patented Differential Drive technology
    • Dual 2" voice coils and a ferrite magnet provide ideal balance of output, weight, and thermal performance
    • 90° x 60° rotatable Progressive Transition waveguide ensures smooth, predictable coverage
    • LF extension reaches down to 50Hz
    • 80Hz high-pass preset available for applications using SRX900 subwoofers
    • 45° monitor angle for use as a high-performance, full-range stage monitor
    • Voicing and phase response optimized to match SRX900 line-source products
    • Integrated amplification delivers plug-and-play operation
    • Rear LCD enables fast configuration
    • DSP includes 24 user-adjustable filters, 2,000ms delay, and essential loudspeaker management tools
    • Seven M10 Quick-Link attachment points included for suspension using standard M10 eye bolts
    • Constructed from outdoor-grade Baltic birch plywood for excellent durability

  • Specifications:

      Acoustical
    • Frequency Range:
      - (-10dB): 50Hz - 20kHz
      - (-3dB): 60Hz - 19kHz
    • Coverage Pattern (-6dB):
      - Horizontal: 90° nominal
      - Vertical: 60° nominal
      - Rotatable: Yes
    • Maximum Peak Output: 134dB SPL
    • System Type: Multi-purpose point-source, two-way powered

      Transducers
    • Low Frequency: 1x JBL 275F, 15" diameter, dual 2.0" diameter voice coil, ferrite Differential Drive
    • High Frequency: 1x JBL 2408H-1, 1" exit neodymium compression driver with 1.5" voice coil

      Audio Input
    • Input Type: Balanced line level
    • Connectors: 2x Neutrik XLR (IN/OUT)
    • Nominal Input Sensitivity: +3 dBu
    • Maximum Input Level: +21 dBu
    • Input Impedance: 100kΩ

      DSP
    • Sample Rate: 48kHz
    • Bit Depth: 24 bit
    • System Latency:
      - Main PA: 7.0ms
      - Monitor: 2.9ms

      User Interface
    • Type: LCD, encoder, Back button, 4x LED Indicators (3x single color, 1x bi-color)

      Physical
    • Enclosure: Exterior grade birch plywood, DuraFlex finish, two integral handholds
    • Color: Black, RAL9005
    • Monitor Angle: 45°
    • Environmental:
      - IP549: IEC 60529
      - ASTM: B11710
      - ASTM: G15510
    • Suspension: 7x JBL QuickLink M10 points
    • Grille: Powder coated 1.5mm (16 gauge) hex perforated steel with acoustically transparent black cloth backing
    • Dimensions (HxWxD): 26.2" x 16.9" x 14.5" (666mm x 428mm x 367mm)
    • Net Weight: 55lbs (24.7kg)
    • Shipping Weight: 67lbs (30.3kg)

  • Item Includes:

    • 1x SRX915M
    • 1x Neutrik NAC3F-TRUE1-S
    • 1x Neutrik NAC3M-TRUE1-S

  • Warranty:

    • 5 Year Limited Warranty
